1192A
® AlPHONE
LOUDSPEAKER INTERCOM SYSTEM
Model:
LEM-IL
(l-call master wtdoor
release button)
INSTRUCTIONS
(on back of unit)
(D
O Speaker/mic.
r?) OFF button
TALK button
Communication volume control
Call tone volume control
Call tone by depressing both
TALK & OFF buttons
Cz) Door release button
MOUNTING ACCESSORIES;
Jt,
I Mounting bracket
I Screw(2)(for
mounting to electrical box)
I Wood
SCTtV/{2)(for mounting to wall surface)
\2
FEATURES
* 1-call loudspeaker master with door release button & call
tone volume control.
* Simple 2-conductor wiring.
* Call a sub by either tone or voice at master.
* Desk-top or wall-mount installation.
* Handsfree remote communication at sub/door station.
