Bolens 135-688-000 - Manual (Page 35)

Models 618, 620, 638, 668, 688 and 698
PARTS LIST FOR
SINGLE SPEED TRANSAXLE 717-0750A
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1 714-0129 #4 Hi-Pro Key 3/32 x 5/8" DIa. 33 736-0188 Fl-Wash. .760" I.D.
X
1.49"
2 716-0115 Snap Ring .625" Shaft O.D.
3 710-0854 Hex Bolt 1/4-20
X
1.75" Lg.* 34 717-0761 Lower Housing
4 710-0809 Hex Bolt 1/4-20
X
1.25" Lg.* 35 750-0555 Spacer .53" O.D.
X
3/8" Lg.
5 717-0764 Upper Housing 36 736-0329 L-Wash. 1 / 4 " I.D.*
6 710-0889 Hex Fl-Bolt 1/4-20 x .88" Lg.* 37 710-0886 Hex Bolt 1 / 4-20 X
1.50" Lg.
7 712-0287 Hex Nut 1/4-20 Thd.* (Grade 5)
8 717-0634 Input Shaft 38 712-0335 Castle Nut 5/16-24 Thd.*
9 721-0178 Square Seal 5/8" I.D. 39 736-0159 Fl-Wash. .344" I.D.
X
.875"
10 736-0335 Thrust Washer 5/8" I.D. x O.D.
1.25" O.D. 40 717-0700 Actuating Arm—R.H.
11 717-0633 Pinion input 14T 41 717-0679 Brake Yoke
12 716-0108 Retaining Ring 7/16" Ext. 42 717-0682 Puck Plate
13 717-0758 Drive Shaft—R.H. 43 717-0678 Brake Puck
14 741-0336 Flange Brg. 5/8" I.D. x У а " 44 717-1011 Axle L.H. N
Lg.* 45 717-0677 Brake Disc
15 * •* Fl-Wash. (See Below) 46 741-0337 Flange Bearing 5/8" I.D. x
16 717-0757 Bevel Gear 42T 15/16" Lg.
17 717-0667 Clutch Collar 47 714-0161 Woodruff Key 3/16
X
5/8 HT
18 717-1010 Miter Gear 15T N 48 717-0754 Shift Fork Ass’y.
19 716-0142 Snap Ring 49 741-0862 Ball Detent .250" Dia.
20 717-0690 Thrust Bearing У 2 " I.D. x 1.0" 50 732-0863 Spring Detent
O.D. 51 714-0169 #9 Hi-Pro Key 3/16"
X W’
21 710-0862 Pan Head Scr. 1 / 4 -20 x .50" Dia. HT
Lg. w/Patch 52 741-0335 Needle Brg. 5/8" I.D. x 1 / 2 "
22 717-1012 Axle R.H. N Lg.
23 741-0340 Sleeve Bearing W I.D. x 53 710-0855 Hex Bolt 1 / 4-20 X
1.00" Lg.
1.0" Lg. 54 736-0336 Fl-Wash. 5/8" I.D. x .030
24 721-0179 Oil Seal 3 / 4 " I.D. 54A 736-0337 Fl-Wash. 5/8" I.D. x .040
25 741-0339 Flange Bearing 3 / 4 " i . d .
x
55 741-0343 Actuating Pin 5/16" Dia.
15/16" Lg. 56 710-0886 Hex Bolt 1 / 4-20 X
1.50" Lg.
26 736-0188 Fl-Wash. .760" I.D. x 1.49" (Grade 5)
O.D. 57 717-0767 Difterential Gear 72T Ass’y.
27 717-0673 Cross Shaft w/Bearing N
28 717-0777 Differential Housing Ass’y. 58 717-0681 Sq. Hd. Bolt 5/16-24 Thd.
29 — Comes with Ref. 28 59 1544-013 Cotter Pin 3/32" Dia. x .50"
30 717-1009 Miter Gear N Lg.
31 712-0200 Hex Ins. L-Nut 1 / 2-20 Thd. 737-0148 Grease—Shell (10 oz.)
‘Ref. No. 15 736-0349 FI-Wash. 5/8" I.D. x 1.0" O.D. x .020 Thk.
736-0336 Fl-Wash. 5/8" I.D. x 1.0" O.D. x .030 Thk.
736-0337 Fl-Wash. 5/8" I.D. x 1.0" O.D. x .040 Thk.
35
