Models 618, 620, 638, 668, 688 and 698
PARTS LIST FOR MODELS 618, 620, 638, 668, 688 AND 698 LAWN TRACTORS
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1
732-0307
Extension Spring .99" O.D.
24
09721
Pivot Link Ass’y.
X
11.00" Lg.
25
738-0140
Shid. Bolt .437" Dia. x .180"
2
741-0313
Flange Bearing .634" I.D.
Lg. (5/16-18)
3
736-0231
FI-Wash. .344" I.D. x 1.125"
26
736-0264
FI-Wash. .344" I.D. x .62"
4
710-0604
Hex Wash. Hd. 5/16-18 x
27
736-0119
L-Wash. 5/16" I.D.*
.62" Lg.
28
712-0267
Hex Nut 5/16-18 Thd.*
5
16063
Adj. Link Lift
29
14633
Index Brkt.
6
711-0738
Stabilizer Rod
30
736-0341
Flange Wash. .628" I.D. x
7
14647
Stabilizer Shaft Ass’y-
1.25" O.D.
9
714-0470
Cotter Pin 1/8" Dia. x 1V4"*
31
735-0216
Rubber Wash. 1.50" O.D.
10
736-0156
FI-Wash. .635" I.D. x 1.12"
32
14654
Retainer Washer—Lift
11
736-0192
FI-Wash. .531" I.D. x .940"
Handle
12
714-0101
Inter. Cotter Pin .50" Dia.
33
14645
Lift Handle Ass’y.
13
14641
Lift Shaft Ass’y-
34
720-0157
Grip (Lift Handle)
14
14802
Link Deck Lift Ass’y.
35
732-0440
Extension Spring .99" O.D.
15
09735
Connecting Rod
X
14.25" Lg.
16
736-0300
FI-Wash. .40" I.D. x .88"
36
710-0118
Hex Bolt 5/16-18
X
.75"*
17
714-0104
Inter. Cotter Pin—3/8" Rod
39
732-0440
Extension Spring (30" & 36"
18
712-0342
Hex Jam Nut 3/8-16 Thd.
RD Decks Only)
19
16064
Adj. Link Lift Ass’y.
40
08540
Knob
21
732-0412
Deck Lift—Down Stop
41
710-0351
Hex AB-Tap Scr. #10 x .50"
22
736-0231
FI-Wash. .344" I.D. x 1.125"
42
725-0803
Safety Switch
O.D.
X
.125
33
