Model 698
PARTS LIST FOR MODEL 698 LAWN TRACTOR
REF.
NO.
NEW
PART
COLOR
CODE DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1 732-0414 Hood Spring N 47 725-0759 Reverse Safety Switch
2 14665 —610 Hood N 48 736-0147 Ext. L-Wash. #10-24 Thd.*
3 712-0272 Hex Sems Nut #10-24 Thd.* 49 712-0121 Hex Nut #10-24 Thd.*
4 736-0463 FI-Wash. .281" l.D. x .62" 50 14607 — Hitch Plate N
O.D. X .06 51 712-0267 Hex Nut 5/16-18 Thd.*
5 723-0302 Hood Stop 7" Lg. 52 736-0119 L-Wash. 5/16" l.D.*
6 710-0437 Truss Hd. Scr. #10-24 x Vz" 54 757-0299 Seat Ass’y.
Lg.* 57 710-0726 Hex Wash. Hd. AB Tap Scr.
7 723-0155 Fuel Cap Gauge 5/16 X .62" Lg.
8 751-0172 Fuel Tank 59 731-0561 Tool Tray N
9 726-0153 Tie Strap 60 14789 —609 Fender Panel (Optional) N
10 751-0173 Fuel Line N 61 726-0151 Fastener
11 726-0183 Hose Clamp 62 736-0338 Fiber Wash.
12 09960 Headlight Retainer 63 710-0437 Truss Hd. Scr. #10-24 x .50"
13 712-0287 Hex Nut 1/4-20 Thd.* Lg.
14 736-0329 L-Wash. 1 / 4 " I.D.* 64‘ 710-0258 Hex Bolt 1 / 4-20 X .62" Lg.*
15 725-0222 Headlight 67 749-0517 Grille Support Rod (R.H. &
16 710-0118 Hex Bolt 5/16-18 X .75" Lg.* L.H.) N
18 14674 Grille Ass’y. N 69 710-0255 Truss Hd. Scr. 1 / 4-20 X .75"
19 722-Ó135 Foam Strip Lg.*
20 731-0534 Battery Box 70 14748 — R.H.—Grille Side Panel N
21 710-0102 Hex Bolt 1 / 4-20 X 2.50" 14749 — L.H.—Grille Side Panel N
Lg.* 71 14620 —609 Dash Panel Ass’y. N
22 14606 —609 Lower Frame N 72 746-0449 Throttle Control Ass’y. N
23 13863 Grille Mount Brkt.—L.H. 73 — Part of Ref. No. 86
24 14619 Front Pivot Brkt. N 74 — Part of Ref. No. 86
25 13862 Grille Mount Brkt.—R.H. 75 725-0267 Ignition Switch
26 710-0726 Hex Wash. Hd. AB-Tap Scr. 76 — Part of Ref. No. 86
5/16 X .62" Lg. 79 725-0201 Ignition Key
27 710-0524 Truss Hd. Scr. 1 / 4-20 X 1.75" 80 710-0493 Hex Bolt 1 / 2-13 X 1.00" Lg.
Lg.* (2-Req’d.)
28 710-0134 Carriage Bolt 1 / 4 -20 x .62" 81 736-0921 L-Wash. 1 / 2 " l.D.* (2-Req’d.)
Lg.* 82 710-0376 Hex Bolt 5/16-18 X 1.00"
29 14604 —609 Running Board (R.H. & L.H.) N Lg.*
30 761-0169 Blade Brake Ass’y. 83 732-0354 Seat Spring
(38" Deck Only) 84 725-0634 Light Switch
33 710-0323 Truss Mach. Scr. 5/16-18 x 85 722-0111 Throttle Control Knob
.75" Lg.* 86 725-0119 Ammeter
36 14671 Fender Clamp N 87 710-0351 Truss Hd. Phil. Scr. #10 x
37 14666 —609 Fender (R.H. & L.H.) N .50" Lg.
38 710-0T18 Hex Bolt 5/16-18 X .75" Lg.* 88 731-0511 Molding Strip 27" Lg.
39 14602 —609 R.H. Side Frame N 89 738-0526 Running Board Rod N
40 710-0258 Hex Bolt 1 / 4-20 X .62" Lg.* 90 712-0287 Hex Nut 1 / 4-20 Thd.*
41 736-0173 FI-Wash. .281 l.D. x .75" 91 710-0198 Hex Bolt 5/16-18 X .75" Lg.*
O.D. 92 710-0599 Thread Rolling Scr. 1 / 4 -20 x
42 712-0287 Hex Nut 1 / 4-20 Thd.* .50" Lg.
43 735-0204 Battery Hold Down 93 735-0144 Rubber Wash. 1 / 2 " l.D. x
44 725-0514 12-V Battery 1.0" O.D.
45 14603 —609 L.H. Side Frame N 94 712-0324 Hex Sems Inst. L-Nut 1 / 4 -20
46 14618 —609 Transmission Panel N Thd.
*For faster service obtain standard nuts, boits and washers
locally. If these items cannot be obtained locally, order by
part number and size as shown on parts list.
(609—Burgundy)
(610—Rose)
When ordering parts, if color or finish is important use the ap­
propriate color code shown above, (e.g. Burgundy Finish—
14606 (609).)
