TABLE I—DIMENSIONS IN INCHES
MODEL & SIZE
A
C
D
E
F
G
H
Vent
Dia
394D-000050
12
46-3/16
10-3/8
9-1/2
14-1/2
27-1/8
32-9/16
4
3940-024050
12
46-3/16
10-3/8
9-1/2
14-1/2
27-1/8
32-9/16
4
394D-000080
14-3/16
46-3/16
12-9/16
11-11/16
14-1/2
27-1/8
32-9/16
4
394D-024080
14-3/16
46-3/16
12-9/16
11-11/16
14-1/2
27-1/8
32-9/16
4
3940-036080
14-3/16
46-3/16
12-9/16
11-11/16
14-1/2
27-1/8
32-9/16
4
394D-000100
17-1/2
46-3/16
15-7/8
15
14-1/2
27-1/8
32-9/16
5
394D-036100
17-1/2
46-3/16
15-7/8
15
14-1/2
27-1/8
32-9/16
5
3940-048100
21
46-3/16
19-5/16
18-1/2
14-1/2
27-1/8
32-9/16
5
394D-000125
21
46-3/16
19-5/16
18-1/2
14-1/2
27-1/8
32-9/16
5
394D-036125
21
46-3/16
19-5/16
18-1/2
14-1/2
27-1/8
32-9/16
5
394D-048125
21
46-3/16
19-5/16
18-1/2
14-1/2
27-1/8
32-9/16
5
394D-060125
21
46-3/16
19-5/16
18-1/2
14-1/2
27-1/8
32-9/16
5
394D-000150
24-1/2
46-3/16
22-7/8
21
14-1/2
27-1/8
32-9/16
6
3940-048150
24-1/2
46-3/16
22-7/8
21
14-1/2
27-1/8
32-9/16
6
394D-060150
24-1/2
49
22-7/8
21
18
29-15/16
35-3/8
6
394B-060150
24-1/2
49
22-7/8
21
18
29-15/16
35-3/8
6
394D-060175
31-1/2
49
29-7/8
29
18
29-15/16
35-3/8
7
394B-060175
31-1/2
49
29-7/8
29
18
29-15/16
35-3/8
7
394B-060200
31-1/2
49
29-7/8 '
29
18
29-15/16
35-3/8
7
TABLE II—RATINGS AND PERFORMANCE*
MODEL
NATURAL and LP
Temp
Rise
Range
Heating
Cooling
Input Btuh
Output Btuh
Ext Static
Pressure
CFM
Ext Static
Pressure
CFM
394D-000050
50,000
40,000
70-100
0.12
408
—
—
3940-024050
45-100
482
0.5
780
394D-000080
80,000
64,000
70-100
0.12
654
—
—
394D-024080
70-100
772
0.5
790
3940-036080
45-100
772
1190
394D-000100
100,000
80,000
70-100
0.15
818
—
—
394D-036100
45-100
965
0.5
1200
3940-048100
45-75
1157
1540
394D-000125
125,000 '
100,000
70-100
0.2
1020
—
—
394D-036125
70-100
1069
0.5
1210
394D-048125
45-100
1206
1560
394D-060125
45-75
1447
2000
394D-000150
150,000
120,000
70-100
0.2
1225
—
—
394D-048150
45-100
1454
0.5
1500
394D-060150
45-75
1736
2080
394B-060150
45-100
1447
2310
394D-060175
175,000
140,000
45-100
0.5
1688
0.5
2010
394B-060175
45-100
1688
2290
394B-060200
200,000
160,000
70-100
0.5
1634
0.5
2460
"The above ratings are certified for altitudes to 2000 ft. For elevations above 2000 ft. reduce ratings 4% for each 1000 ft. above sea
level.
