Aiphone MY-1AD - Manual (Page 6)

a
SPECIFICATIONS
* Power source
* Current consumption
* Calling
* Communication
♦Wiring
♦Wiring distance
♦Video monitor
* Scanning line
♦Dimensions
♦Weight
DC 18V. Use a power supply adaptor PS-18YB, 18YC or 18YD.
0.9A maximum. 0.15A in standby mode.
4-stroke electronic chime
Simultaneous with handset.
Single pair, straight conductors (non-polarized) between video door station and MY-1 AD.
Diameter 0.65 mm 1.0 mm
Distance i 50 m 100 m
AWG 22 AWG 18 AWG
Distance 165' 330'
4 inch direct view CRT.
525 lines.
H: 210 mm x W: 186 mm x D: 53.5 mm (8-1/4" x 7-5/16" x 2-1/8")
; Approx. 1.1 kg (2.43 lbs.).
1 WARRANTY
f
Aiphone warrants its products to be free from defects of material and workmanship under normal use and service for a period of one
year after delivery to the ultimate user and will repair free of charge or replace at no charge, should it become defective upon which
examination shall disclose to be defective and under warranty. Aiphone reserves unto itself the sole right to make the final decision
^ whether there is a defect in materials and/or workmanship; and whether or not the product is within the warranty.
This warranty shall not apply to any Aiphone product which has been subject to misuse, neglect, accident, or to use in violation of
instructions furnished, nor extended to units which have been repaired or altered outside of the factory.
This warranty does not cover batteries or damage caused by batteries used in connection with the proauct.
2 This warranty covers bench repairs only, and any repairs must be made at the shop or place designated in writing by Aiphone, Aiphone
^ will not be responsible for any costs incurred involving on site service calls.
Aiphone Co., Ltd., Nagoya, Japan
Aiphone Corporation, Bellevue, Washington, USA
MY-1AD-1(E)0890F
^1^^ INTERCOM SYSTEMS
® AIPHONE
HOME, BUSINESS, INDUSTRY
Printed in Japan (E)
6
-
