INSTALLATION
L (1)
Actual terminal location
MY-1 AD BACK VIEW
(2) Wall mounting
—
__________ n
Al ,
A2
; Connect to A1 , A2 terminals on
MY-DA (non-polarized).
0
> SG
: Connect to
j
1 2 terminals on IER-2.
(non-polarized).
L+ ,
L-
: Connect to electric door release and bell
transformer.
output plug with cord
approximately 190 cm(6'-3")
long.
-a
POWER SUPPLY
CONNECTING WIRES
CONNECTING WIRES
(3) Desk-top use
CONNECTING WIRES
-STAND
Select a location where the MY-1 AD unit will not fall or where the cable may cause tripping.
