PARTS LIST FOR MODEL 120-270A
1 PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION NEW
PART
731-0314 Shroud 44 710-0459 Hex Bolt 3/8-24 X 1.50"
J 710-0227 Hex Wash. Hd. AB-Tap Scr. Lg. H.T.
#8 X .38" Lg. 45 736-0119 L-Wash. 5/16" l.D.*
3 —
Engine 46 712-0123 Hex Nut 5/16-24 Thd.*
4 10381 Engine Brkt. Ass’y- 47 10530 Spring Lever Ass’y. w/Knob
5 736-0300 FI-Wash. .385" l.D. x.87" 48 11679 -462 Chute Deflector Ass’y.
O.D. X .06 Comp.
6 712-0116 Elastic L-Nut 3/8-24 Thd. 49 738-0269 Shid. Bolt
7 10913 —462 Drive Cover 50 736-0255 Belleville Washer
8 710-0289 Hex Bolt 1/4-20 X .50" Lg.* 51 10619 Pivot Bar
9 736-0222 External L-Wash. V a " 1.6.* 52 710-0289 Hex Bolt 1/4-20 X .50" Lg.
10 716-0106 “E”-Ring for 5/8" Shaft 53 711-0555 Pivot Pin
11 10914 Drive Pinion 54 11130 Adapter Plate
12 02265 Sleeve .44" Dia. x 16 Ga. 55 710-0603 Hex Wash. Hd. Self-Tap Scr.
13 748-0227 Hex Flange Brg. .630 l.D. 5/16-18 X . 50" Lg.
Bronze 56 732-0253 Torsion Spring
14 10370 Pivot Plate Ass’y. 57 738-0102 Axle Bolt—Rear
15 716-0106 “E”-Rlng for 5/8" Shaft 58 734-0843 Wheel Ass’y. Comp.—Rear
16 736-0116 FI-Wash. .635" l.D. x .93" 59 12322 Index Plate Ass’y.—R.H.
O.D. X .060 60 11197 -462 Protective Shield Ass’y.—
17 748-0227 Hex Flange Brg. .630" l.D. Comp.
Bronze 61 14164 Handle Mtg. Brkt. Ass’y.
18 10372 Drive Support 62 14165 Handle Mtg. Brkt. Ass’y.
19 711-0435 Drive Shaft 63 710-0567 Hex Bolt 1/4-28 X .62" Lg.
20 715-0247 Roll Pin 3/16" Dia. X 1.00" 64 736-0119 L-Wash. 5/16" l.D.*
Lg.* 65 710-0442 Hex Bolt 5/16-18
21 10378 Sprocket Ass’y. 8 Tooth X 1.50" Lg.*
22 713-0135 Chain w/Master Link #48 x 66 714-0104 Hairpin Cotter
26" Lg. 67 711-0570 Engagement Ferrule
12613 Clutch Rod 68 749-0392 Lower Handle N
732-0433 Tension Spring 69 726-0188 Cable Tie
25 731-0124 Hub Cap 70 746-0380 Throttle Control Ass’y.
26 738-0144 Axle Bolt—Front Only Comp.
27 736-0160 FI-Wash. .385" l.D. x .87 O.D. 71 710-0606 Hex Bolt 1/4-20 X 1.50"
x .06 Lg.*
28 734-0880 Front Wheel Ass’y. Comp. 72 718-0145 Grip
29 10918 Link Ass’y. 73 749-0384 Upper Handle N
30 736-0105 Belleville Washer 74 710-0405 Curved Hd. Bolt 5/16-18 x
31 12321 Index Plate Ass’y.—L.H. 1 1/4 "
32 12421 —462 Deck Ass’y. 75 09966 Hand Knob
33 710-0654 Hex Wash. Hd. Self-Tap 76 710-0352 Hex Bolt 1/4-28 X 3/8" Lg.*
Scr. 3/8-16 X . 88" Lg. 77 715-0246 Spring Pin Spiral 3/16 x 1.25"
34 712-0107 Hex Cent. L-Nut V4-20 Thd. Lg.
35 712-0375 Hex Cent. L-Nut 3/8-16 Thd. 78 736-0329 L-Wash. 1/4" l.D.*
36 12323 Index Plate 79 13708 Bearing Support
37 710-0209 Sems Hex Bolt 3/8-16 x .62" 80 10377 Sprocket Ass’y. 8 Tooth
Lg.* 81 746-0381 Conduit and Wire
38 714-0365 #6 Hi-Pro Key 5/32 x 5/8" 82 726-0134 Speed Nut #8-32
Dia. 83 715-0247 Roll Pin 3/16" Dia. X 1.00"
39 10769 Blade Adapter Kit Lg.*
40 742-0125 22 Inch Blade 85 731-0344 Plastic Label
41 10769 Blade Adapter Kit 86 726-0106 Push Cap
42 736-0217 L-Wash. 3/8" l.D. 87 741-0262 Fortiflex Bearing
Heavy Duty 88 748-0142 Flange Bearing
43 710-0117 Hex Bolt 5/16-24 X 1.00" 89 751-0109 Dip Stick
Lg. H.T.
(462—Red Flake)
When ordering parts if color or finish is important, use the ap­
propriate color code shown above, {e.g. Red Flake
Finish—10913(462).)
17
NOTE; The engine is not under warranty by
the mower manufacturer ... If repairs or
service is needed on the engine, please
contact your nearest author-
a —^-------------------- -
ized engine service outlet. Find It Fast
Check the “Yellow Pages" of In The
your telephone book under Yellow Pages
“Engines—Gasoline.”
