Avanti DG24CSS - Manual (Page 27)

spare Part List
page;
2 / 2
Customer
Customer Product Code
Product Code
Description
Exploded Drawing No
Revision
Valid Thru
:AVANTI
:DG24CW
:TFB21USA04
:14 JUN 2000
No Code Description Unit Quantity
57 12756H07 TF3 DRAWER GUIDE WITH CONSOLE,RIGHT PCS 1
58 12756H08 ТГЗ DRAWER GUIDE WITH CONSOLE,LEFT PCS 1
59 13010251 TFS/G/A INNER GLASS LOW-E PCS 1
60 13010835 TF3 I SOX GLASS PCS 1
61 14520105 TFG/3/A KNOB SPRING PCS 5
62 14560101 CLIP PCS 1
63 14550103 THERMOSTAT CLIP PCS 2
64 14560106 MICRO SWITCH SPRING PCS 4
65 14560107 SEGMENT OF SPARKING PLUG PCS 3
66 15050283 TFB BOTTOM STYRAPHOR PCS 1
67 15050349 TFB/G SPLASH GUARD REAR STYRAPHOR PCS 1
68 15050350 TFB/G SPLASH guard FRONT STYRAPHOR PCS 1
69 15050353 TF3/G RIGHT SACK STYRAPHOR PCS 1
70 15050354 TF3/G LEFT FRONT STYRAPHOR PCS 1
71 15050360 ТГЗ PLATE STYRFOR PCS 1
72 15Q51E11 TFG/3 OUTER TRAY PCS 1
73 15062S11 TFG/B/A INKER TRAY PCS 1
74 15759501 ТГЗ SPLASH PLINTH (USA) PCS 1
75 16011075 TFG21 INSTRUCTION MANUAL PCS 1
7 6 16011085 TFa2IUSA03/04/06AVANTI INSTRUCTION MANUAL PCS 1
77 1504 1567 TF3/G LOWER PART OF OVEN KNOB,WHITE PCS 1
78 16041558 TF3/G LOWER PART OF HOB KNOB PCS 4
79 15099K53 SOURDILLION HOB TAP KNOB(PROFILE TYPE) PCS 4
80 155 07N OVEN TAP KNOB PCS 1
81 17C10136 TF3/A INNER GRID PCS i
32 17020220 TFB TWIN COOKING GRID PCS 2
83 17098E11 MEDIUM BURNER COVER (AESTHETIC) PCS 2
84 17099211 SMALL BURNER COVER (AESTHETIC) PCS 1
85 17107211 BIG BURNER COVER PCS 1
86 17405N TF321 GAS DELIVERY PIPE PCS 1
87 17674N TFG-321 GRILL BURNER GAS DELIVERY PIPE PCS 1
88 17579N ГГ5 SACK LEFT GAS DELIVERY PIPE PCS
1
89 17530N TF3 FRONT LEFT GAS DELIVERY PIPE PCS 1
90 1753 IN TFB FRONT RIGHT GAS DELIVERY PIPS PCS i.
91 17 5 52N TFB BACK RIGHT GAS DELIVERY PIPS PCS 1
92 17592K01 TF3.'G/R OVEN BURNER GROUP PCS 1
93 i8o:o:oi TF3-TFG WIRE RACK SYSTEM FIXING NUT PCS 2
94 18010206 TF321 SPLASH PLINTH BACK COVER PCS 1
95 13755H02 TERMINAL BLOCK (1000 DS\3) PCS I
96 23424519 TF321USA04 AVANTI BOX PCS 1
97 25004H73 TF321 HIRING TREE PCS 1
98 60015408 POWER SUPPLY CORD PCS 1
99 6005:201 OVEN LAMP,T300,15W,120-.130V PCS 1
100 60054303 TOA41 MICRO SWITCH PCS 4
101 600-1401 TFG21 INNER ILLUMINATION BUTTON,PUSH ON-PUSH PCS 1
102 6102:336 TF3.TFG/TFR 0.30 INJ. HOB TAP PCS L
103 61C 2 3 3 37 TF3.TFG/TFR 0.39 INJ. HOB TAP PCS 2
104 6102:338 TF3/TFG/TFR 0.45 INJ. HOB TAP PCS 1
105 61021104 TFG21 GAS REGULATOR PCS 1
106 61040603 LOWER SEAL FOR TAP (TFG/B/S) PCS 4
107 68020107 RIGHT HINGE PCS 1
108 68C20200 LEFT HINGE PCS 1
109 6302:300 HINGE BUSHING PCS 2
