Poulan CHDF550D - Manual (Page 17)

TROUBLESHOOTING POINTS
PROBLEM CAUSE CORRECTION
Will not start 1. Out of fuel.
2. Engine not “CHOKED” properly.
3. Engine flooded.
4. Ditty air ciearier.
5. Water in fuel.
6. Clogged fuel tank.
7. Loose spark plug wire.
8. Bad spark plug or Improper gap.
9. Carburetor out of adjustment.
1. Fill fuel tank.
2. See “TO START ENGINE” in the Operation section.
3. Wait several minutes before attempting to start.
4. Clean or replace air cleaner cartridge.
5. Drain fuel tank and carburetor, and refill tank with
fresh gasoline.
6. Remove fuel tank and clean.
7. Make sure spark plug wire is seated properly on plug.
8. Replace spark plug or adjust gap.
9. Make necessary adjustments.
■lard to start 1. Throttle control not set properly.
2. Dirty air cleaner.
3. Bad spark plug or improper gap.
4. Stale or dirty fuel.
5. Loose spark plug wire.
6. Carburetor out of adjustment.
1. Place throttle control in “FAST” position.
2. Clean or replace air cleaner cartridge.
3. Replace spark plug or adjust gap.
4. Drain fuel tank and refill with fresh gasoline.
5. Make sure spark plug wire is seated properly on plug.
6. Make necessary adjustments.
.OSS of power 1. Engine is overloaded.
2. Dirty air cleaner.
3. Low oil level/dirty oil.
4. Faulty spark plug.
5. Oil in fuel.
6. Stale or dirty fuel.
7. Water in fuel.
8. Clogged fuel tank.
9. Spark plug wire loose.
10. Dirty engine air screen.
11. Dirty/clogged muffler.
12. Carburetor out of adjustment.
13. Poor compression.
1. Set depth stake and wheels for shallower tilling.
2. Clean or replace air cleaner cartridge.
3. Check oil level/change oil.
4. Clean and regap or change spark plug.
5. Drain and clean fuel tank and refill, and clean
carburetor.
6. Drain fuel tank and refill with fresh gasoline.
7. Drain fuel tank and carburetor, and refill tank with
fresh gasoline.
8. Remove fuel tank and clean.
9. Connect and tighten spark plug wire.
10. Clean engine air screen.
11. Clean/replace muffler.
12. Make necessary adjustments.
13. Contact an authorized service center/department.
Ingine overheats 1. Low oil level/dirty oil.
2. Dirty engine air screen.
3. Dirty engine.
4. Partially plugged muffler.
5. Improper carburetor adjustment.
1. Check oil level/change oil.
2. Clean engine air screen.
3. Clean cylinder fins, air screen, muffler area.
4. Remove and clean muffler.
5. Adjust carburetor to richer position.
ixoessive bounce/
iifficult handling 1. Ground too dry and hard.
2. Wheels and depth stake incorrectly adjusted.
1. Moisten ground or wait for more favorable soil
conditions.
2. Adjust wheels and depth stake.
Soil bails up or clumps 1. Ground too wet. 1. Wait for more favorable soil conditions.
ingine runs but tiller 1. Tine control is not engaged. 1. Engage tine control.
lon’t move 2. V-belt not correctly adjusted.
3. V-belt is off pulley(s).
2. Inspect/adjust V-belt.
3. Inspect V-belt.
ingine runs but labors 1. Tilling too deep. 1. Set depth stake for shallower tilling.
/hen tilling 2. Throttle control not properly adjusted.
3. Carburetor out of adjustment.
2. Check throttle control setting.
3. Make necessary adjustments.
17
