TABLE OF CONTENTS
SPECIFICATIONS.................................................... 2
SPECIAL SAFETY SECTION.................................. 3
KNOW YOUR UNIT................................................ 6
ASSEMBLY .............................................................. 7
A Getting Ready..................................................... 7
B. Attadungthe Bar and Chain............................... 7
C. Chain Tension.................................................... 8
PREPARING YOUR SAW FOR USE
9
A Fuel Safety ......................................................... 9
B. Fuel Mixture...................................................... 9
C. Use The Following Only................................... 9
D. Do Not Use The Following.. ............................ 9
E. How to Mix Fuel and Fill Thnk....................... 9
F. Bar and Chain Oil............................................ 10
USING YOUR SAW................................................. 11
A Pre-Operation Checks.........................................11
B. Starting Instructions .........................................11
TYPES OF CUTTING.............................................. 12
A Basic Cutting Technique ...................................12
B. Ti^ Felling Techniques ................................. 12
C. Bucking........................................................... 14
D. Debranching and Pruning............................... 15
GENERAL MAINTENANCE..................................16
A Guide Bar and Chain......................................... 16
B. Spaik Arrestor................................................. 17
C. Starter Rope..................................................... 18
D. Carburetor Adjustments ................................. 19
E. Air Filter........................................................... 20
F. Storage .............................................................20
G. Trouble Shooting Chart....................................21
H. Maintenance Chart........................................... 22
ACCESSORIES.........................................................23
PARTS & SERVICE............................... Back Cover
Throttle
Lock-out
Hand Guard
Reduced Kickback
Low-Kickback Giude Bar
Chain
I
READ
SAFETY SECTION
FREQUENTLY
Handlebar
Choke
Knob
Starter
Handle
Trigger Muffler Bar Clamp
Rear
Handle
TfflS SAW IS INTENDED
FOR OCCASIONAL USE ONLY
Oil Cap
Start/Stop
Fuel Cap
Switch
SPECIFICATIONS
MODEL:
2100
2400
DISPLACEMENT:
2.0 cu. in. (33 cc)
2.3 cu. in. (37 cc)
GUIDE BAR:
14” Guide Bar — Part No, 952-044368
18” Guide Bar — Part No. 952-044418
16” Guide Bar — Part No. 952-044370
CHAIN:
3/8 Pitch, 91SG-52 (14”) — Part No. 952-051209 3/8 Pitch, 91SG-62 (18”) — Part No. 952-051338
3/8 Pitch, 91SG-56 (16”) — Part No. 952-051211
SPARKPLUG:
Champion (C5J-8)
SPARK PLUG GAP:
.025”
IGNITION;
Solid State
MODULE AIR GAP:
.008” to .014”
OILER:
Automatic
FUEL MDC:
Gasoline/Oil Mixture - 40:1 (see “Fueling Your Engine”)
MUFFLER:
Temperature Limiting/Spark Arresting
Manufactured under on or more of the following US. Patents: 4,197,641^ 4,302,879; 4,940,Ш8.
-
