Poulan 2000-11 - Manual (Page 45)

TRACTOR - MODEL NUMBER 271470
MOWER DECK
KEY PART KEY PART
HO. NO. DESCRIPTION NO. NO. DESCRIPTION
1 170280 Mower Housing Assembly 56 165723 Spacer, Retainer
72140506 Bolt. Carriage 5/16H8x3/4 67 149846 Knob
Í 138017 Bracket Asm. Fram Sway Bar 68 144200 Belt
1 169970 Bracket, Asm, Deck Sway 69 76020312 Pin, Cotter 3/32 X 3,14
Bar 86 7631J Runner, LH
i 4939M Retainer. Spring 87 128772 Runner. RH
5 130832 Asm, Suspension Rear 88 19111216 Washer 11/32 x 3/4 x 16 Ga
■- 850857 Bolk Hex 3/8-24 X 1-1/4 Gr 8 89 19131612 Washer 13/32 x 1 x 12 Ga
10030600 Washer. Lock, Hid Sprg 3/8 107 133502 Spacer. Retainer
0 140296 Washer, Hard Blade Mower 108 133503 Stiffener. Idler Arm
Vented 109 74760640 Bolt, Hex Head 3/8-16x2-1/2
1 134148 Blade, Mower, Mulching 38" 110 142587 Upstop Deck Front 38"
3 137645 Shaft and Bearing Assembly 113 17060512 Screw 5/16-18x3/4
(Includes Key Number 15) 122 131289 Rod, Brake, LH
4 128774 Mandrel Housing, Vented 123 169971 Rod, Brake, RH
5 110485X Ball Bearing, Mandrel 146 165891 Bolt Carriage Idler
6 140329 Stripper, Mower, Vented 148 169022 Spring Return Idler
9 132827 Bolt, Shoulder 149 165898 Retainer Spring Yellow Zinc
1 73680500 Nut, Crownlock 5/16-18 150 19091216 Washer 9/32 x 3/4 x 16 6a
3 137607 Bracket, Mower Deflector 151 169670 Bracket Clulch
4 105304X Cap, Sleeve 152 172758 Cable Clutch 38 In
5 123713X Spring, Deflector 153 169674 Washer Flat 3/8" Type B
6 110452X Nut, Push 154 169675 Spring Retainer
7 106736X428 Shield, Deflector 155 169671 Spring Retention Lever
8 19111016 Washer 11/32 x 3./4 x 16 Ga 156 169672 Spacer
9 106735X Rod, Hinge 157 169669 Rod Clutch
^0 157722 Screw, Thdro Washer Hd 158 17720410 Screw Hex Thd Cut
i1 129963 Washer, Spacer 1/4-20x5/8
153532 Pulley, Mandrel 130794 Mandrel Assembly (Includes
>3 137266 Nut, Flangelock 9/16 Key Numbers 12-15, 17-19,
131494 Pulley. Idler, Flat 31 and 33)
-0 73680600 Nut Crownlock 3/8-16 171665 Mower Deck, Complete
•5 4497H Retainer, Spring
i'4
130840
133943
Brake Assembly
WasherHardened
NOTE; All component dimensions given in U, S.
5 133840 Idler Arm Assembly
inches 1 inch ~ 25.4 mm
