ENGINE
TRACTOR - MODEL NUMBER 271470
KEY
NO.
PART
NO. DESCRIPTION
1 170551 Control Th/ch
2 17720410 Screw Hex Thd Cut 1/4'20x5/8 T
3 Engine Briggs Model 28R707-1147-El
4 137348
(Order parts from Engine Manufacturer)
Muffler
13 165231 Gasket Eng 1 313 Id Tin Plated
14 148456 Tube Drain Oil Easy
16 11050600 Washer Lock Ext Tooth 3/8
23 169837 Shield Browning
29 137180 Kit Spark Arrestor (Flat Scrn)
31 109202X Tank Fuel Front 1 25
32 140527 Cap Asm Fuel
33 123487X Clamp HoseBIk
37 137040 Line Fuel 20“
38 148315 Plug Drain Oil Easy
40 124028X Bushing Snap Nyl BIk Fuel Line
44 17670412 Screw Hexwsh Thdro! 1/4-20 x 3/4
45 17000612 Screw Hex Wsh Thdro! 3/8-16
46 19091416 Washer 9/32 x 7/8 x 16 ga
62 10040500 Washer Lock Hvy Hid Spr 5/16
72 71070512 Screw Hexhd Cap 5/16-18 x 3/4
78 17060620 Screw 3/8-16 X 1-1/4
81 73510400 Nut Keps Hex 1/4-20 UNC
NOTE : All component dimensions given in U. S.
inches 1 inch = 25.4 mm
39
