REPAIR PARTS
DRIVE
. ‘ , - M Q l x f l -‘.aiVibr'^
KEY PART KEY ■ PART
NO. NO. DESCRIPTION NO. NO. DrS€R!f‘T!ON
1 Transaxle (See Breakdown) 55 105709X "jpriiiu ri.jich Return •
Peerless 206-508B 56 74760620 bfiliFin.le* ’7-16x1-1/4
2 146682 Spring, Return, Brake 57 130801 V ReH Ground Drive
3 123666X Pulley, Transaxle 58 127274X Keeper Belt. R H.
4 12000028 Ring, Retainer 59 140312 Keeper Belt, Center Span
5 121520X Strap, Torque 61 17490612 Screw Thd , Roll. 3/8-16x3/4
6 17490512 Screw, Thd., Roll. 5/16-18 x 3/4 62 8883R Cover, Pedal
8 141003 Rod Shifter Fender LT 63 140186 PulKy, EngifK
10 76020416 Pin, Cotter 64 71170764 Bolt. Hex Head, Fin.
11 10570IX Washer, Shift Plate t 4 Grade 5
13 74550412 Bolt 1/4-28 UNF W/Patch Gr. 8 65 10040700 Washer
14 10040400 Washer 66 154778 Keeper, Beit, Engine^ Fool-Proof
18 74780616 Bolt Fin Hex 3/8-16 UNC x 1. Gr5 70 134683 Guide Mower Drive Belt, R.H.
19 73800600 Nut 72 19132012 Washer 13/32 x 1-1/4 x 12 Ga.
21 106933X Knob 74 137057 Spacer, Axle
22 130804 Rod, Brake 75 121749X Washer 25/32 x 1-1/4 x 16 Ga.
24 73350600 Nut 76 12000001 E-Ring
25 106888X Spring, Brake Rod 77 123583X Key, Square 2.0 x .1845/.1865
26 19131316 Washer 78 121748X Washer 25/32 x 1-5/8 x 16 Gauge
27 76020412 Pin 79 2228M Kev Woodruff #9 3/16 x 3/4
28 145204 Rod, Parking Brake 80 131486 Arrfi, Shift
29 71673 Cap, Parking Brake, Black 81 161076 Shaft Assembly
30 130807 Bracket, Transaxle 82 123782X Spring, Torsion
31 127275X Keeper, Belt, L.H. 83 19171216 Washer 17/32 x 3/4 x 16 Ga.
32 74760512 Bolt 84 123793X Tie Rod
34 155071 Shaft Assembly, Foot Pedal 85 150360 Nut, Nylock
35 120183X Bearing, Nylon 86 157480 Bushing
36 19211616 Washer 87 19212016 Washer
37 1572H Roll Pin 88 12000008 E-Ring
38 131494 Pulley, Idler, Flat 89 139964X428 Console, Shift, LT
39 74760644 Bolt 90 124346X Nut. Self-Thding, Wsh Hd 1/4
40 4470J Spacer, Split .395 x .59 96 4497H Retainer Spring 1”
41 165838 Keeper, Belt, Idler Fool-Proof 112 19091210 Washer 9/32 x 3/4 x 10 Gauge
42 19131312 Washer 13/32 x 13/16 x 12 Ga. 113 127285X Strap Torque Lh Lt
47 127783 Pulley, Idler, V-Groove, Plastic 116 72110610 Bolt Rdhd Sqneck 3/8-16 x 1.25
48 154407 Bellcrank Clutch Grnd Drv StI 145 74490540 Bolt, Hex Flghd 5/16-18 Gr. 5
49 123205X Retainer, Belt 148 159103 Spacer
50 74760624 Bolt 149 122052X Spacer Retainer PM Mower
51 73680600 Nut Crown Lock 3/8-16 UNC 150 150935 Bushing Nylon Collered
52 73680500 Nut Crown Lock 5/16-18 UNC 151 19133210 Washer 13/32 x 2 x 10 Ga.
53 10571 OX Link, Clutch
NOTE:
1 inch = 25.4 mm.
