TO REMOVE HOOD AND GRILL ASSEMBLY
(See Fig. 29)
•
Raise hood.
' Unsnap headlight wire connector.
•
Stand in front of tractor. Grasp hood at sides, tilt toward
engine and lift off of tractor.
FIG. 29
Che
ible.
djustmentas-
djustment i's
adj.i (II.
era
tiu
Il(*
II.
I
hi.
.
-I
/
described
below
before loosening c;
necessary, prc^eed
as
follows;
• With
engine
not running,
move
throttle control lever
from slow to choke position. Slowly move lever from
choke to fast position.
e Check that holes “A” in governorcontrol lever and hole
in governor plate line-up. If holes “A" are not aligned,
loosen clamp screw and move throttle cable until holes
are aligned. Tighten clamp screw securely.
TO ADJUST CARBURETOR ^
-
The carburetor has been preset at the factory and adjust
ment should not be necessary. However, minor adjust
ment
may be required to compensate for differences in fuel,
temperature, altitude or load. If the carburetor does need
adjustment, see engine manual.
High speed stop is factory adjusted. Do not adjust -
damage may result.
IMPORTANT;
NEVER TAMPER WITH THE ENGINE
GOVERNOR. WHICH IS FACTORY
SET
FOR PROPER
ENGINESPEED. OVERSPEEDING THE ENGINE ABOVE
THE
FACTORY
HIGH
SPEED
SETTING
CAN
BE
DANGEROUS. IF YOU THINK THE ENGINE-GOVERNED
HIGH SPEED NEEDS ADJUSTING, CONTACT YOUR
NEAREST
AUTHORIZED
SERVICE
CENTER/
DEPARTMENT, WHICH HAS PROPER EQUIPMENT AND
EXPERIENCE
TO
MAKE
ANY
NECESSARY
ADJUSTMENTS.
