SPECIFICATIONS
Maximum Height—51"
Height with Handlebars off— 17-V4"
Width (at Handlebar Grips)— I
6
-V
4
"
Tilling Width— 9" (approx.)
Tilling Width (outer tines off)— 6" (approx.)
Tine Construction— stamped steel, heat-treated,
non-interchangeable
Controls: Engine Throttle Speed Lever
Engine Ignition Switch
Fuel Primer Button or Choke Lever
Depth Stake
Starting System— Manual rope pull (automatic
rope rewind)
Fuel Tank Capacity— 20 ounces
Engine Make: Tecumseh TC-200-2106
Engine Type: two-cycle (2-stroke), air-cooled.
Engine Displacement: 32.8cc (2 cu in). 1.6HP
Maximum Engine RPM: 5200
Fuel Mix Requirements: Use a ratio of 24 parts
of unleaded regular gasoline to 1 part of quality
30 or 40 weight two-cycle engine oil. See Page
12 in the Manual for specific instructions.
Engine Lubrication: Quality two-cycle engine oil
must be mixed in the correct ratio (see above)
with unleaded regular gasoline.
Spark Plug: Champion CJ8Y; Champion RCJ8Y
for use in Canada. Gap plug to .030".
MAINTENANCE RECORD
DATE HOURS USED MAINTENANCE PERFORMED
23
