PARTS LIST FOR MODEL MTD2105A98 FRONT TINE TILLER
REF.
NO.
PART
NO.
DESCRIPTION
PART
NO.
DESCRIPTION
1
04648
Belt Guard
34
746-0620B
Clutch Control Cable
2
04657A
Bracket
(Reverse)
3
04704A
Belt Retainer
35
751-0233
Muffler Deflector
4
710-0118
Hex Bolt 5/16-18
X
75" Lg.’
36
5 H.P.
Engine—B&S 130202-3166-01
5
710-0191
Hex Bolt 3/8-24 x 1 25" Lg.*
37
754-0189
V-Belt 44" Lg.
6
710-0198
Hex Sems Scr, 5/16-18 x
38
754-0255
V-Belt 37" Lg.
.75" Lg.
39
756-0221
Transmission Pulley
7
710-0342
Hex Bolt 3/8-16
X
1 25'' Lg.'
40
756-0223
Engine Pulley
8
710-0380
Hex Bolt 5/16-18
X
1,75"
41
756-0225
Fl-ldier Pulley
42
784-0221
Tine Idler Brkt. Ass’y.
9
710-0451
Carr. Bolt 5/16-18 x .75" Lg.
47
784-0226
Clutch Cable Bracket
10
710-0157
Hex Boll 5/16-24
X
.75" Lg.
48
784-0237
Idler Bracket Ass'y.
11
710-0599
Hex TT-Tap Scr. 1/4-20 x .5"
49
784-0240
Tine Shield
Lg.
50
784-0241
Belt Guard
12
710-0642
Hex TT-Tap Scr. 1/4-20 x
51
784-0246A
Brkt. Tine Shield
.75" Lg.
Reinforcement
13
710-0643
Hex L-Scr. 5/16-18 x 1.0" Lg.
52
784-0250
Mounting Plate Ass’y-
14
710-0783
Hex Wash. Hd. Slotted Scr.
53
04697
Tiller Frame Ass’y.
#8-32
X
.38" Lg.
54
717-0304
Transmission Ass'y. Comp.
15
712-0116
Hex Ins. L-Nut 3/8-24 Thd.
(See Breakdown)
16
712-0185
Speed Nut 1/4-20 Thd.
55
714-0149B
Internal Cotter Pin
17
712-0241
Hex Nut 3/8-24 Thd,
56
1545-029
Clevis Pin
18
712-0267
Hex Nut 5/16-18 Thd.'
61
710-0899A
Hex Sems Scr. #10-32 x .62"
19
712-0798
Hex Nut 3/8-16 Thd •
Lg.
20
714-0105
Sq. Key 3/16^ 1,0"
62
751-0360A
Casing Clamp
21
714-0126
#9 Hi-Pro Key 3/16 < 3/4"
70
04675
Inner Tine Adapter Ass'y.
22
725-0157
Cable Tie
Comp.—L.H.
23
726-0106
Cap Speed Nut 1/4 Rod
71
04673
inner Tine Adapter Ass'y.
24
732-0562
Extension Spring 3-5/8" Lg.
75
710-0191
Hex Bolt 3/8-24 x 1.25" Lg.'
25
736-0315
F^Wash. 3/4" I.D. x 1.5" O.D.
76
712-0241
Hex Nut 3/8-24
26
736-0119
L-Wash. 5/16" I.D.'
78
742-0107
Tine 14"—L.H.
27
736-0119
L-Wash. 5/16" I.D.*
79
742-0108
Tine 14"—R.H.
28
736-0133
FI-Wash. .406"
X
1.25"
x
80
04676
Inner Tine Adapter Ass’y.
.10"
Comp.—R.H.
29
736-0142
FI-Wash. .281 I D. x .50 O.D.
81
04695
Outer Tine Adapter Ass’y.
x .063"
Comp.—L.H.
30
736-0169
L-Wash. 3/8" I.D.'
82
06797
Outer Tine Adapter Ass’y.
31
736-0231
FI-Wash. .344"
X
1.125"
X
83
04696
Outer Tine Adapter Ass'y.
.125"
Comp.—R.H.
32
738-0372
Shoulder Spacer
84
735-0639
Spark Plug Boot
33
746-0619B
Clutch Control Cable
(Forward)
'For faster service obtain standard nuts, bolts, and washers local
ly. If these items cannot be obtained locally, order by part number
and size as shown on parts list.
