TRACTOR PARTS LIST
RE#
NO.
PART
NO.
roSi description NO. REQ'D.
REF. PART
NO. NO.
STOCK
CODE
DESCRIPTION NO. REQ'D.
1 70009 M Flange Whiziock Screw 5/16-18 x 1/2 11 84 65056 F Locknut 1/4-20 Plated 9
2 24208 F Outer Salt Guard 1 85 24077 M Shaft Support 4
3 72066 F Belt 1 86 24072 s Shift Link 2
4 60012 M Setscrew 5/16-18 X 3/8 3 88 612999 s Differential Assembly 1
S 59053 M Cap Screw 5/16-24 x 3/4 Plated 2 89 73049 s Sheave 1
6 63003 M Lockwasher 5/16 Plated 11 90 05077 F Locknut 5/8-18 1
7 24025 s Brace 1 91 10372 M Locknut Hub 1
8 24165 M R. H. Belt Finger 1 92 24079 s Idler Arm 1
9 59080 M Cap Screw 1/4-20 x 5/8 3 93 11031 s Spacer 2
10 64002 M Washer 5/16 Wrought Plated 8 94 12132 s Idler 2
11 24074 M Roller Chain 38P. 1 95 24162 s Idler Arm 1
12 24166 M L. H. Belt Finger 1 96 59039 M Cap Screw 5/16-18 X 1/2 3
13 24087 s Engine Sheave 1 97 64052 M Washer, Special, Plated 1
14 66018 M Key 1 98 10260 s Wave Washer 1
15 524006 0 Cover 1 99 67004 F Cotter Pin 1/8 X 1 Plated 2
16 24091 M Lower R. H. Handlebar 1 100 10144 M Clevis Pin 1
17 24093 s Upper Hendlebar 1 101 83094 s Spring, Extension 2
18 65040 M Locknut 1/4-20 Pleted 6 102 24059 0 Clutch Fork 1
19 75006 M Grip 2 103 67010 F Hair Cotter Pin 1
20 24073 M Roller Chain 22P. 1 104 24069 0 Fork Pivot Rod 1
21 6Ó3948 s Tire and Wheel Assembly 2 105 24095 0 Adjustment Rod 1
Consists of Following: 106 65062 M Nut 5/16-18 Nylok 1
M 71021 Tire 1 107 54039 M Ball Bearing 2
s 71077 Rim 1 108 22002 S Spindle Housing 1
M 71087 Tube (Available) 1 109 24155 S Braring Spacer 1
22 59050 M Cap Screw 1/4-20 x 1-1/2 Plated 5 110 22003 s Drive Spindle Housing 1
23 61017 M Machine Screw 10-24 x 5/8 Rd. Head 2 111 3034 M Roller 2
24 524007 0 Dash 1 112 59003 M Cap Screvir 5/16-18 x 1 Plated 3
25 75019 M Knob 1 113 66006 M Key, Woodruff No. 3 1
26 69080 F Throttle Control 1 114 24076 s Spindle 1
27 24090 M Clutch Rod 1 115 10546 M Drive Disc 1
28 24092 M Lower L. H. Hendlebar 1 116 65015 F Nbt 5/16-18 Platad 4
29 22071 M Clutch Handle 1 117 24044 0 Frame 1
30 65051 M Keps Nuts 10-24' Plated
2 118 24086 M Rod Adaptor Spacer 1
31 74039 s Tapping Screws
■ '.2;, 119 24071 M Drive Disc Spacer 1
32 22129 s Handle Pivot 1 120 24081 s Carrier Shaft 1
33 59062 - M Cap Screw 1 121 24084 0 Clutch Engagement Yoke 1
34 63004 F Lockwasher 3/8 Plated 4 122 55026 M Flange Buying 4
35 65018 F Nut 4 123 524001 0 Disc Carrier 1
36 24088 s Upper Shift Rod 1 124 10542 s Adaptor Spacer 1
37 67016 F CottarPin 2 125 3003 F Friction Wheal 1
38 65042 F Locknut 5/16-18 Plated 6 126 24075 S Friction Disc Hub 1
39 24094 S Control Handle 2 127 54093 M Radial Bearing 4
40 83015 S Spring, Compression 2 128 57021 M Snap Ring 1
41 10248 S Shift Ball 2 129 24045 0 Hex Shaft 1
42 24140 S Shift Handle 2 130 65086 M Locknut 1
43 58004 F Roll Pin 1/4x11/2 2 131 66015 M Key, Woodruff No. 5 1
44 24083 0 Activating Shaft 1 132 10276 S Sprocket 1
45 59022 F Cap Screw 5/16-18 x 3/4 Platad 2 133 63025 M Lockwasher 1
46 24096 S Upper Attachment Clutch Rod 1 134 3085 s Bearing Flange 1
47 83095 S Spring, Compression 1
135 54080 s Bearing 1
48 58034 F Roll Pin 1/8 X 3/4 1
136 24141 s Bearing Flange 1
49 24095 S Lower Attachment Clutch Rod 1 137 64093 F Washer 4
SO 22135 M Rod Adaptor 3 138 65054 M Locknut 1/2-20 Jam, Plated 1
51 58033 F Roll Pin 5/32 X 3/4 ,1
141 24080 s Pinion Shaft 1
52 24157 S Lever 1
142 58029 F Roll Pin 5/32 X 1 4
53 65041 F Locknut 10-24 4 143 64039 M Washer, Special, Plated 2
54 55037 F Flange Bushing 4 144 524002 s Pinion and Sprocket 1
55 70026 M Nut Retainer 2 145 22093 M Zerk Fitting 1
56 67001 F Cotter Pin 3/32 X 3/4 Platad 4 146 624012 0 L, H. Axle 1
57 78250 0 Cover Decal 1 147 55029 M Bushing 2
58 67004 F Cotter Pin 1 148 10374 s Pin 1
59 64057 M Washer, Special, Plated 2 149 83007 S Spring Compression 1
60 65031 M Nut 5/16-24 Plated 1 150 60012 M Setscrew 1
61 78248 0 Shift Label 1 151 3017 s Bearing Flange 2
62 78240 0 In-Out Label 1 153 10142 s Bearing Flange 2
63 78241 0 Throttle Control Decal 154 64056 M Washer 2
64 78059 0 Caution Decal 1 156 70015 F Flange Whiziock Screw It
65 10228 s Lower Shift Rod 1 157 65039 F Locknut 3/8-16 2
66 24082 s Shift Laver 1 158 64058 F Washer 2
67 24047 s Reduction Sprocket Shaft 1 159 510004 s Lock Hub Assy. 1
66 624021 s Reduction Sprocket W/Bushings 1 160 59057 M Cap Screw 5/16-18x2 2
69 24029 s Support 1 161 78249 0 Disc Adjustment Decal 1
70 10215 0 Shift Lever Bracket 162 55040 M Bushing 2
71 12151 s Clevis Pin 2 163 24056 0 Bracket 1
72 58032 F Roll Pin 3/32 k 1 1 164 59028 M Cap Screw 2
73 10375 s Knob 1 165 63002 M Lockwasher 2
74 78038 0 Differential Lockout Decal 1 Not Illustrated
75 58042 M Groove Pin 1/4 x 1-3/4 78148 Engine Label 1
76 24187 0 Bottom Cover 1 78189 Air Cleaner Decal 1
77 3377 0 Hub Cap 1
78 10366 s Push Nut 1 SUGGESTED PARTS-Engine (Tecumsah HSK-80-155020) 1
79 3376 s Spindle Cup 1 STOCKING CODE
80 70032 s Wheel Bolt 1/2-20 8 F - Fast
A.
81 24117 0 R. H. Axle Shaft 1 M - Medium -Order Replacement Engine anil/or
82 58003 F Roll Pin 3/16x1-1/4 1 s - Slow Fngins replacement parts from your
83 64036 M Washer, Special 3 0- Customer Order Only nearest engine servita central.
