24’’ SNO-THRO PARTS LIST FOR MODELS 924026, 924028,924032
SOUFFLEURS SNO-THRO DE 24” MODELES 924026, 924028, 924032
REF. part stock
NO. NO. CODE
No OE No DE CODE
REF. PIECE D'lNV.
DESCRIPTION
QTY.
QUANTITÉ
REF. PART STOCK
NO. NO. CODE
No DE No DE CODE
REF. PIECE D'lNV.
DESCRIPTION
QTY.
QUANTITÉ
1 64046 M Washer 1.505 0D. x 1.005 10. 2 52 24329 S Chute Control Crank 1
2 70012 M Flange Whitlock Screw 5 53 22123 S Worm Clevis 1
3 56061 M Seal 2 54 22110 S Worm Gear 1
4 10181 S Case Cover 1 55 58034 F Roll Pin 1/8 X 3/4 5
5 10108 M Gasket 1 56 63023 M Lockwasher 1
6 55035 M Bushing 2 57 65042 F Locknut 5
7 10299 s Rake Shaft 1 58 10438 S Chute Clamp 3
8 58030 M Roll Pin 3/16 X M/2 2 59 524021 0 Blower Housing (24") 1
9 72083 F V Belt 1 60 54063 M Ball Bearing 1
10 524015 S Worm Gear and Shaft 1
61 3017 M Bearing Flange 1
11 1138 S Pipe Plug 2 62 64002 F Washer 5/16 9
12 10180 S Gear Case 1
63 10164 F Scraper Blade 1
13 57032 M Snap Ring 1
65 10165 F Runner 2
14 54044 M Bearing Cup 2
66 70011 M Ribbed Neck Bolt 1/4 x 5/8 6
15 54045 M Bearing Cone 2
67 10184 M Bearing Support 2
16 58022 M Roll Pin 1 68 65056 F Whitlock Nut 1/4-20 6
17 58007 F Roll Pin 1/4 X 11/4 1
69 64047 F Washer 1.441 O.D. x .5111 2
18 67OÎ0 S Hair Cotter 1
70 63006 F Lockwasher 1/2 2
19 10371 S Adiustment Plug 1
71 59024 M Cap Screw 1/2-13 x 1 Hex. Hd. 2
20 56062 F Seal 1
72 22093 F Zerk Fitting 4
21 24237 M Fan 1
73 510015 F Shear Bolt 2
22 62010 M Carriage Bolt 3/8-16 x 3/4 5
74 510007 0 R.H. Rake 1
25 24276 S Discharge Chute 1 75 510008 0 L.H. Rake 1
26 59023 F Cap Screw 3/8-16 Hex. Hd. 2 76 62026 M Carriage Bolt 5/16-18 x 1/2 5
27 74054 F Taptite No. 10-24 x 3/8 6 77 524016 S Gear Case Assembly 1
28 10193 M Wing Nut 1
78 64043 M Washer 1
29 510012 M Deflector, W/Decal 1 79 10494 s Worm Shaft 1
30 65039 F Locknut 3/8-16 6 80 65015 F Nut 5/16-18 1
31 63004 F Lockwasher 3/8 2 81 10107 M Bearing Spacer 1
32 60012 F Setscrew 5/16-18 x 3/8 2 82 67004 F Cotter Pin 1
33 73042 S Sheave 1 83 22178 M Lining 1
34 66001 M Key, Woodruff No. 11 1 84 68062 M Rivet 2
35 55035 M Bushing 2 85 83164 M Spring 1
44 24327 M Eyebolt 1
86 62011 F Carriage Bolt 5/16-18 x 3/4 1
45 65040 F Locknut 1/4-20 7 87 58037 M Roll Pin 1/4 X 13/4 2
46 10142 M Bearing Flange 1
88 63032 M Lockwasher 1
47 10198 s Cap 1
89 70031 M Flange Whitlock Screw 2
48 75083 s Grip 1
90 10289 M Eyebolt 1
49
50
624035
24328
s
s
Brake, w/lining
Rod
1
1
NOTE: F0R OECALS SEE PAGES 2 8t 3
51 622020 M Universal Joint 2 POUR DECALQUES VOIR P. 2 8i 3
SUGGESTED PARTS STOCKING CODE
S -SLOW
0 - Customer Order Only
F - FAST
M -MEOlUM
COOE SUGGERE D'INVENTAIRE DES PIECES
F - FAST (rapide) S -SLOW (lent)
M - MEOlUM (moyen) 0 - Commande du client seulement
