SNO-THRO DIFFERENTIAL KIT MODEL 710983
Ref.
Part
No.
Ref.
Part
No.
No.
No.
Description
Req'd
No.
No.
Description
Req'd.
1
10354
Zerk Fitting
1
12
58003
Roll H n 3/16 X 1-1/4
1
2
10366
Push N ut
1
13
58037
Roll Pin 1/4 X 1-3/4
1
3
610938
L.H . Axle
1
14
58032
Roll Pin 3/32 X 1
1
4
10370
R.H . Axle Shaft
1
15
64036
W asher 1.380 O .D . x .880 I.D .
X.062 1
5
10372
Lockout H ub '
1
16
64042
W asher 2" O .D . x 3/4" LD . x
1/8" 1
6
10374
Pin
1
17
65056
W hizlock N ut 1/4-20
6
7
10375
Knob
1
18
70011
Ribbed N eck Bolt 1/4-20
6
8
12023
Bearing Support
2
19
78038
D ifferential Lock D ecal
1
9
612999
D ifferential Assem bly
1
20
83007
Spring
1
10
55029
Bushing (In 12008)
2
21
337é
Spindle Cup
1
11
55030
Ashing (In 12023)
2
MODEL 710997 SUCER BAR KIT
FOR ALL MODELS
# 62009 CARRIAGE BOLT
5/16-18x1/2"
