Ariens 924000 - Manual (Page 27)

TRACTOR PARTS FOR MODELS 924032,
924033, 924024, 924025, 924026, 924027
PIÈCES DU TRACTEUR DES MODÈLES 924032,
924033, 924024, 924025, 924026, 924027
No DE No DE CODE
REF. PIÈCE D'INV.
REF. PART STOCK
NO. NO.
QUANTITÉ
DESCRIPTION
^ ir>
CM CH
o o
CM CM O) o>
CM CO
CO CM
o o
CM CM o> O)
<0
CM CM
o o
CM CM 0> O)
QTY. QTY. QTY.
8/32 7/24 8/24
No DE No DE CODE
REF. PIÈCE DMNV.
REF. PART STOCK
NO. NO.
QUANTITÉ
DESCRIPTION
^ to
CM CM
o o
CM CM o> a>
CM CO
8S
SS
o> a>
to
CM CM
o o
CM CM 0> O)
QTY. QTY. QTY.
8/32 7/24 8/24
1 70009 M FLANGE WHIZLOCK SCREW 6 6 6 49 24243 S LOWER ATTACHMENT Clutch Rodi 1 1
2 24208 F OUTER BELT GUARD 1 1 1 50 22135 M ROD ADAPTOR 1 1 1
3 72066 F BELT 1 — — 51 58033 F ROLL PIN, 5/32x3/4 1 1 1
3 72084 F BELT — 1 1 52 24157 S LEVER 1 1 1
4 60012 M SETSCREW, 5/16-18x3/8 3 3 3 54 55036 F FLANGE BUSHING 2 2 2
5 59053 M CAP SCREW, 5/16-16-24 X 3/4 2 2 2 55 70026 M NUT RETAINER 2 2 2
Plated 56 67001 F COTTER PIN 3/32 x 3/4 Plated 1 1 1
6 63003 M LOCKWASHER, 5/16 Plated 2 2 2 57 66011 KEY, Feather 2
7 24025 s BRACE 1 1 1 58 67018 F COTTER PIN 2 2 2
8 24253 M BELT FINGER, Engine 1 1 1 60 65031 M NUT 5/16-24 Plated 1 1 1
g 59080 M CAP SCREW, 1/4-20 x 5/8" 3 3 3 61 24322 AXLE 1
10 64002 M WASHER, 5/16 Wrought 6 6 6 64 63019 O LOCKWASHER, Special 1 1 1
13 24087 s SHEAVE, Engine 1 1 1 65 24247 S LOWER SHIFT ROD 1 1 1
14 66018 M KEY
1 1 1
76 24234 0 BOTTOM COVER 1 1 1
15 624063 0 COVER 1 1 1 77 3377 0 HUB CAP 1 2 1
16 24268 M LOWER L.H. HANDLEBAR 1 1 1 78 10366 s PUSHNUT 1
1
17 524023 M UPPER HANDLEBAR W/Decal 1 79 3376 s SPINDLE CUP 1 2 1
17 524019 M UPPER HANDLEBAR W/Decal 1 1 80 70032 s WHEEL BOLT 1/2 -20 8 6 6
18 65040 M LOCKNUT, 1/4-20 Plated 8 8 8
81 24117 0 R.H. AXLE SHAFT 1
19 75006 M GRIP 2 2 2 81 10370 0 R.H. AXLE SHAFT 1
21 610960 S TIRE & WHEEL ASS'Y. 2 2 82 58003 F ROLL PIN 3/16 X 1-1/4 1 1
Consists of Following: 83 67014 M COTTER PIN 2
M 71046 Tire 1
87 55037 M FLANGE BUSHING 2 2 2
s 71052 Rim 1
88 612999 S DIFFERENTIAL ASS'Y. 1 1 1
M 71050 Tube 1
■ 88 10211 s SPUR GEAR 1
21 603948 S TIRE 8t WHEEL ASS'Y. 2
92 24226 s IDLER ARM 1 1 1
Consists of Following:
94 12132 s IDLER 2 2 2
M 71021 Tire 1
95 24222 s IDLER ARM 1 1 1
s 71077 Rim 1
97 64052 M WASHER, Special, Plated 1 1 1
M 71087 Tube (available) 1
98 10260 s WAVE WASHER 1 1 1
22 59050 M CAP SCREW, 1/4-20 x VA Plated 5 5 5
99 67004 F COTTER PIN, 1/8 X 1 Plated 3 3 3
23 61012 M MACHINE SCREW, 10-24 x 1/2 HH 2 2 2
101 83094 S SPRING, Extension 1 1 1
24 524020 0 DASH 1 1 1
105 12131 s BEARING SPACER 1 1 1
25 75019 M KNOB 1 1 1
117 24274 0 FRAME 1
26 69080 F THROTTLE CONTROL 1 1 117 24275 0 FRAME 1 1
26 69180 F THROTTLE CONTROL 1
128 66012 M KEY, Woodruff SAE 91 1
27 24265 M CLUTCH ROD 1 137 64093 F WASHER 2 2 2
27 24244 M CLUTCH ROD 1 1 140 58016 S ROLL PIN 2
28 24267 M LOWER R.H. HANDLEBAR 1 1 1 151 3017 s BEARING FLANGE 2
29 22071 M CLUTCH HANDLE 1 1 1 152 59069 M CAP SCREW 2 2 2
30 65051 M KEPS NUT 10-24 Plated 2 2 2 154 64078 F WASHER 2 2 2
31 74039 s SCREW, Self Tapping 2 2 2 156 70015 F FLANGE WHIZLOCK SCREW 2 2 2
32 22129 s HANDLE PIVOT 1 1 1 157 64036 F WASHER 1 1 1
33 59062 M CAP SCREW 1 1 1 160 59057 M CAP SCREW, 5/16-18 X 2 2 2 2
34 63004 F LOCKWASHER, 3/8 Plated 4 4 4 161 69012 O CLIP 1 1 1
35 65018 F NUT 4 4 4 163 24225 0 BRACKET 1 1 1
36 24245 S UPPER SHIFT ROD 1 1 1 164 59028 M CAP SCREW 2 2 2
37 64007 F WASHER 1 1 1 165 63002 M LOCKWASHER 2 2 2
38 65042 F LOCKNUT, 5/16-18 Plated 5 5 5 166 24323 M AXLE HUB 2
39 24240 S CONTROL HANDLE 2 2 2 167 11134 M SWITCH 1 1 1
40 83015 S SPRING, Compression 2 2 2 168 65075 M NUT, Special 1 1 1
41 10248 S SHIFT BALL 2 2 2 185 65032 F NUT, Hex 1 1 1
42 24241 S SHIFT HANDLE 2 2 2 186 24221 S UPPER ROD, Interlock 1 1 1
43 58056 F ROLL PIN, 1/4 X
VA 2 2 2 187 67003 F COTTER PIN 1 1 1
44 24083 0
ACTIVATING SHAFT 1 1 1 188 22147 M HANDLE, Interlock 1 1 1
45 59022 F CAP SCREW, 5/16-18 X % Plated 1 1 1 189 22148 M PIN, Pivot 1 1 1
46 24096 S UPPER ATTACHMENT Clutch Rod 1 1 1 190 22153 F PUSHNUT 1 1 1
47 83095 S SPRING, Compression 1 1 1 192 11031 S SPACER 1 1 1
48 58034 F ROLL PIN, 1/8 X 3/4 1 1 1 193 13157 S KEY 1 1 1
SUGGESTED PARTS STOCKING CODE
F - FAST S -SLOW
M - MEDIUM 0 - CUSTOMER ORDER ONLY
CODE SUGGÉRÉ D'INVENTAIRE DES PIÈCES
F - FAST (rapide) S -SLOW (lent)
M — MEDIUM (moyen) 0 — Commande du client seulement
NOTE: FOR DECALS SEE PAGES 2 8t 3
Page 27
NOTE: DÉCALQUES (voir p. 2 & 3)
