32" SNO-THRO PARTS LIST FOR MODELS 924042 & 924044
SOUFFLEURS SNO-THRO DE 32" MODELES 924042 & 924044
NobE NODE CODE
REF. PIECi D'INV
DESCRIPTION
REF. PART STOCK
NO. NO. CODE
QUANTITÉ
NO. REQ'D
N ode
REF.
REF.
NO.
No DE CODE
PIECE D'INV.
PART STOCK description
NO. CODE
QUANTITÉ
NO. REQ'D
1 064046 M WASHER, 1.000/1.010 x .505 x 1/16 2 51 024401 S EYEBOLT 1
2 059001 M CAP SCREW, 1/4-20 x 3/4 4 52 024340 S CHUTE CRANK 1
3 056070 M SEAL 2 53 022123 S WORM CLEVIS 1
4 024013 S GEAR CASE COVER 1 54 022110 S WORM GEAR
5 002008 M GASKET 1 55 058034 F ROLL PIN, 1/8 X 3/4 4
6 055059 M BUSHING 2 56 063023 M LOCKWASHER 1
7 024065 s RAKE SHAFT 1 57 065042 F LOCKNUT 6
8 058030 M ROLL PIN, 3/16x101/2 2 58 010438 S CHUTE CLAMP 4
9 072108 F VBELT 1 59 524029 0 BLOWER HOUSING 1
10 524009 S WORM 1 60 054052 M BALL BEARING 1
11 001138 S PIPE PLUG 1 61 031859 M BEARING FLANGE 1
12 024002 S GEAR CASE 1 62 064002 F WASH E R, 5/16 X 7/8 X. 083 10
13 057032 M SNAP RING 1 63 024373 F SCRAPER BLADE 1
14 054044 M BEARING CUP 2 64 083164 M SPRING 1
15 054045 M BEARING CONE 2 65 029225 F SKID SHOE 2
16 002005 M BEARING SPACER 2 66 070011 M RIBBED NECK BOLT 6
17 058015 F ROLL PIN, 5/16x1-3/4 2 67 010184 M BEARING SUPPORT 2
18 024375 S WORM SHAFT 1 68 065056 F FLANGE WHIZLOCK NUT 6
19 024015 S ADJUSTMENT PLUG 1 69 064047 F WASHER, .506/.516X 1.441 X 1/8 2
20 056061 F SEAL 1 70 063006 F LOCKWASHER 2
21 024376 M FAN 1 71 059024 M CAP SCREW, 1/2-13x1 2
22 062010 M CARRIAGE BOLT, 3/8-16x3/4 3 72 022093 F SPIN DRIVE ZERK FITTING 4
23 624035 S BRAKE ARM ASSEMBLY 1 73 510015 F SHEAR BOLTW/NUT 2
24 067019 M HAIRPIN 1 74 024262 0 RIGHT RAKE 1
25 024403 s DISCHARGE CHUTE 1 75 024261 0 LEFT RAKE 1
26 059023q F CAP SCREW, 3/8-16x3/4 2 77 524005 S GEAR CASE ASSEMBLY 1
27 074054 F TAPTITE 8 78 024346 M ROD 1
28 010193 M WING NUT 1 79 010494 S WORM SHAFT 1
29 510012 M DEFLECTOR CHUTE 1 80 065015 F NUT 1
30 065039 F LOCKNUT 6 81 066013 M KEY, Straight 3/16x3/16x1 1
32 024389 S PULLEY HUB 1 83 063032 M LOCKWASHER 1
33 073070 S SHEAVE 1 86 062026 M CARRIAGE BOLT 6
34 066001 M KEY, Woodruff, 3/16x7/8 1 87 062013 M CARRIAGE BOLT, 3/8-16 X 1 2
35 055035 M FLANGED BUSHING 2 88 624065 F UNIVERSAL JOINT ASSEMBLY 2
36 063017 M LOCKWASHER 4 89 064043 M WASH E R, 3/8 X 13/16 X. 065 1
37 064087 F WASHER, 1.623/1.627 x 2.500 x .012 2 90 067010 M HAIR PIN, 3/32x 1-27/64 1
38 060011 M SETSCREW 2 91 070053 M RIBBED NECK BOLT 3
39 066008 M KEY, Woodruff No. 6 2 92 059028 F CAP SCREW, 1/4-20x1/2 1
40 024064 s GEAR CASE SHAFT 1 93 024345 M CLEVIS PIN 1
41 070031 M FLANGE WHIZLOCKSCREW 2 94 024408 M WASHER 2
42 004037 s DUST CAP 1 95 067020 M HAIRPIN 1
43 059022 F CAP SCREW, 5/16-18x3/4 1 96 010260 M WAVE WASHER 1
44 063003 F LOCKWASHER 1 97 022178 M LINING 1
45 065040 F LOCKNUT 6 98 068062 M RIVET 2
46 031860 M BEARING FLANGE 1 99 065078 F WHIZLOCK NUT 3
47 010198 S CAP 1 100 062011 M CARRIAGE BOLT 1
48 075083 s KNOB 1 101 067010 M HAIRPIN 2
49 064082 M WASHER 1
50 024341 s ROD HANGER 1
I
SUGGESTED PARTS STOCKING CODE
F - FAST S -SLOW
M - MEDIUM O - CUSTOMER ORDER ONLY
CODE SUGGËRË D'INVENTAIRE DES PIÈCES
F - FAST (rapide) S -SLOW(lent)
M - MEDIUM (moyen) 0 - Commande du cli|nt seulement
