Ariens 924000 - Manual (Page 49)

SNO-THRO PARTS LIST MODEL 924016
b
REF,
N0.
PART
N0.
Description QTY. REF
NO.
PART
NO.
Description QTY.
1 64046 M Washer 1.505 O.D.x 1.0051.D. 2 47 10198 S Cap 1
2 59001 M Cap Screw 1/4-20 x 3/4 Hex. Hd. Plated 4 48 75039 S ‘ Grip 1
3 56070 M Seal 2 49 64082 M Washer 1
4 24013 S Case Cover 1 50 22065 s Chute Control Bracket 1
5 2008 M Gasket 1 51 622010 M Universal Joint 1
6 55059 M Bushing 2 52 24097 s Chute Control Crank 1
7 24065 s Rake Shaft 1 53 22123 s Worm Clevis 1
8 58030 M Roll Pin 3/16 X 1-1/2 2 54 22110 s Worm Gear 1
9 72072 F V Belt 1 55 58034 F Roll Pin 1/8 X 3/4 2
10 524009 S Worm Gear & Worm 1 56 63023 M Lockwasher 1
11 1138 S Pipe Plug 1 57 65042 F Locknut 8
12 24002 S Gear Case 1 58 10438 S Chute Clamp 3
13 57032 M Snap Ring 1 59 24264 0 Blower Housing (32") 1
14 54044 M Bearing Cup 2 60 54063 M Ball Bearing 1
15 54045
M Bearing Cone 2 61 3017 M Bearing Flange 1
16 2005
M Spacer 2
62 64002 F Washer 5/16 11
17 58015 F Roll Pin 5/16 X 1-3/4 2
63 24256 F Scraper Blade 1
18 24062
S Worm Shaft 1 65 10165 F Runner 2
19 24015 S Adjustment Plug 1
66 70011 M Ribbed Neck Bolt 1/4-20 x 5/8 6
20 56061 F Seal 1
67 10184 M Bearing Support 2
21 24185
M Fan 1 68 65056 F Whiziock Nut 1/4-20 6
22 62010
M Carriage Bolt 3/8-16 x 3/4 3
69 64047 F Washer 1.441 0.0 x.511 2
25 10437 s Discharge Chute 1 70 63006 F Lockwasher 1/2 2
26 59023 F Cap Screw 3/8-16 x 3/4 Hex. Hd. 2 71 59024 M Cap Screw 1/2-13 x 1 Hex. Hd. 2
27 74026 F
Taptite No. 10^24 x 3/8 6 72 22093 F Zerk Fitting 4
28 10193 M
Wing Nut 1 73 510015 F Shear Bolt 2
29 510012
M
Deflector 1 74 524013 0 R.H. Rake 1
30 65039
F
Locknut 3/8-16 6 75 524014 0 L.H. Rake 1
31 63004
F
Lockwasher 3/8 2 76 62026 M Carriage Bolt 5/16-18 x 1/2 7
32 60012
F
Setscrew 5/16-18 X 3/8 2 77 524005 s Gear Case Assembly 1
33 73042
S
Sheave 1 78 62018 M Carriage Bolt 5/16-18 -1-3/4 1
34 66001
M
key, Woodruff No. 11 1 79 10494 s Worm Shaft 1
35 55035
M
Bushing 2 80 65015 F Nut 5/16-18 3
36 63017
M
Lockwasher 1/4 Plated 4 81 66013 M Key 1
37 64087
F
Washer 2 83 78222 0 Caution Label 1
39 66008
M
Key, Woodruff No. 6 2 84 78244 0 Ariens Name Plate 1
40 24064 s
Gear Case Shaft 1 86 62011 M Carriage Bolt 5/16-18 X 3/4 1
41 70031
M
Flange Whiziock Screw 3/8-16 x 1/2 2 87 62013 M Carriage Bolt 2
42
43
44
45
4037
59022
63003
65040
s
F
F
F
Cap
Cap Screw 5/16-18 x 3/4 Hex. Hd. Plated
Lockwasher 5/16 Plated
Locknut 1/4-20
1
1
1
3
88 67013 F Hair Pin 1
46 10142 M Bearing Flange 1 SUGGESTED PARTS STOCKING CODE
F - Fast
M - Medium
S - Slow
0 - Customer Order Only
►
I
Page 49
