Ariens 924000 - Manual (Page 19)

TRACTOR PARTS FOR MODELS 924032, 924033, 924034,
924035,924024, 924025, 924026, 924027 AND WIRING DIAGRAM
■^PIECES DU TRACTEUR DES MODELES 924032, 924033, 924034, 924035,
. 924024, 924025, 924026, 924027 DIAGRAMME DU FILAGE ELECTRIQUE
No DE
REF.
REF.
N0.
No DE CODE
PIÈCE D’INV.
PART STOCK
NO. CODE
QUANTITÉ
m Tj- m cMCO coc*
52 Ç2 CM CM CO CO cm cm
DESCRIPTION $ § § § § §
§ 2
CM CN CM CM CM CM CM CM
0>0>0)0) 0)0) O) O)
QTY. QTY.QTY.
10/32 8/32 7/24 8/24
124 10542 S ADAPTOR SPACER 1 1 1
125 3003 F FRICTION WHEEL 1 1 1
126 24075 S FRICTION WHEEL HUB 1 1 1
127 54093 M RADIAL BEARING 4 2 2
129 24045 0 HEX SHAFT 1
129 24338 0 HEX SHAFT 1 1
130 65086 M LOCKNUT 1 1
131 66015 M KEY, Woodruff No. 5 1 1 1
132 10276
s
SPROCKET 1 1 1
133 63025 F WASHER, Special 1 1
134 3085 S BEARING FLANGE 1 1 1
135 54080
s BEARING 1 1 1
136 24141 s BEARING FLANGE 1 1 1
137 64093 F WASHER 2
138 65054 M LOCKNUT, '/2-20, Jam, Plated 1 1 1
139 63014 M LOCKWASHER 2
141 24080
s PINION SHAFT 1 1 1
142 58029 F ROLL PIN, 5/32 X 1 4 4 4
143 64039 M WASHER, Special Plated 2 2
2
144 524002
s
PINION/SPROCKET 1 1 1
145 22093 M ZERK FITTING 2 1
146 624012 0 L.H. AXLE 1
146 610938 0 L.H. AXLE 1
147 55029 M BUSHING 2 2
148 10374
s
PIN 1 1
149 83007
s SPRING COMPRESSION 1 1
150 24227
s
ADAPTOR 1 1 1
151 12023
s BEARING SUPPORT 2 2
153 10142
s
BEARING FLANGE 2
155 55030 M FLANGE BUSHING
2
155 55039 M FLANGE BUSHING 2
156 70015 F FLANGE WHIZLOCK SCREW 10 10 10
158 64058 F WASHER 2 2 2
159 70011 M RIBBED NECK BOLT 6 6
162 55040 M BUSHING 2 2 2
164 59028 M CAPSCREW 1/4-20x1/2 2 2 2
169 63018 M LOCKWASHER, Internal 3 3 3
170 624027 S SPRING ASSEMBLY 1 1 1
171 70015 F FLANGE WHIZLOCK SCREW
1/4-20 X 1/2 2 2 2
172 24251 M SWITCH ACTIVATOR 1 1 1
173 75045 M SWITCH BOOT 1 1 1
174 25172 M SWITCH 1 1 1
175 24220 0 ROD RETAINER 1 1 1
176 74054 F TAPTITE 2
2
2
177 22167 0 WIRING HARNESS 1 1 1
178 69066
s
CLIP 1 1 1
179 24330 SPACER 1 1 1
180 524010 M MODULE "T" W/Conn. 1 1 1
181 25203 M CONNECTOR 1 1 1
182 59097 F CAP SCREW, No. 10-24x3/8 2 2 2
183 65051 M KEPS NUT No. 10-24 2 2 2
184 24219 S LOWER ROD, Interlock 1 1
22152 S LOWER ROD, Interlock 1
191 24246 S SWITCH RETAINER 1 1 1
195 64123 WASHER 1 1 1
196 3017 M FLANGE 1
197 25089
s
SPACER 1 1
7 H.P. Engine (Tecumseh HSK-70 1302100
or replacement)
8 H.P. Engine (Tecumseh HMSK-80 1551280
or replacement)
10 H.P. Engine (Tecumseh HMSK-100
159024C or replacement)
No DE No DE
REF. PIÈCE
CODE
D'INV.
DESCRIPTION
REF. PART STOCK
OUANTITÉ
< l i > T f t n C M C O (DP-.
S CO CM CM n « CM CM
O O O O O O O
CM CM CM CM CM CM CM CM
OiOlOiOi Oi Oi 0) 0)
QTY. OTY. OTY.
NO. NO. ( CODE 10/32 8/32 7/24 8/:
1 70009 M FLANGEWHIZLOCK SCREW 8 8 8
4 60012 M SETSCREW, 5/16-18x3/8 1 1 1
6 63003 M LOCKWASHER, 5/16 Plated 5 5 5
11 24074 M ROLLER CHAIN, 38P 1
12 75050 M SNAP BUSHING 1 1 1
18 65040 M LOCKNUT, 1/4-20 Plated 2 2 2
20 24073 M ROLLER CHAIN 22P 1
20 12078 M ROLLER CHAIN, 34P 1 1
35 65018 F NUT 2
38 65042 F LOCKNUT, 5/16-18 Plated 3 3 3
45 59022 F CAP SCREW, 5/16-18 X % Plated 1 1 1
50 22135 M ROD ADAPTOR 1 1 1
53 65094 F LOCKNUT, 10-24 4 4 4
56 67001 F COTTER PIN, 3/32 x 3/4 Plated 3 3 3
59 24236 M BELT FINGER 1 1 1
61 75040 O PLUG (heater box) (not ill.) 1 1 1
62 24278 O GROUND WIRE 1 1 1
63 22161 O SHORTING WIRE 1 1 1
66 24232
s SHIFT LEVER 1 1 1
67 524008 S REDUCTION SPROCKET SHAFT 1
68 624021
s
REDUCTION SPROCKET 1
W/Bushings
69 24230
s
SUPPORT 1
69 24339
s
SUPPORT 1 1
70 24231 O SHIFT LEVER BRACKET 1 1 1
71 12151
s CLEVIS PIN 2 2 2
72 58032 F ROLL PIN, 3/32 X 1 1 1
73 10375 S KNOB 1 1
75 58042 M GROOVE PIN, 1 / 4 x 1 % 1 1
8 4 65056 F LOCKNUT, 1/4-20 Plated 6 6 6
85 24077 M SHAFT SUPPORT 4 4 4
86 24233 S SHIFT LINK 2 2 2
89 73049
s
SHEAVE 1 1 1
90 65077 F LOCKNUT, 5/8-18 1 1 1
91 10372 F LOCKNUT HUB 1 1
93 59136 M CAP SCREW 1 1 1
96 59039 M CAP SCREW, 5/16-18 X ’/2 4 4 4
100 24115
s
SPACER 1 1 1
101 83094
s
SPRING, Extension 1 1 1
102 24272 O CLUTCH FORK 1 1 1
103 67002 F COTTER PIN 2 2 2
104 24069 O FORK PIVOT ROD 1 1 1
106 65062 M NUT, 5/16-18 Nylock 1 1 1
107 54039 M BALL BEARING 2 2 2
108 22002
s SPINDLE HOUSING 1 1 1
109 24155
s BEARING SPACER 1 1 1
110 22003
s DRIVE SPINDLE HOUSING 1 1 1
111 3034 M ROLLER 1 1 1
112 59003 M CAP SCREW, 5/16-18 X 1 Plated 1 1 1
113 66006 M KEY, Woodruff No. 3 1 1 1
114 24076
s SPINDLE 1 1 1
115 10546 M DRIVE DISC 1 1 1
116 65015 F NUT, 5/16-18 Plated 4 4 4
118 24086 M ROD ADAPTOR SPACER 1 1 1
119 24071 M DRIVE DISC SPACER 1 1 1
120 24081
s
CARRIER SHAFT 1 1 1
121 24228 O CLUTCH ENGAGEMENT YOKE 1 1 1
122 55026 M FLANGE BUSHING 4 4 4
123 524011 O DISC CARRIER 1 1 1
SUGGESTED PARTS STOCKING CODE
F - FAST S -SLOW
M - MEDIUM 0 - CUSTOMER ORDER ONLY
CODE SUGGÉRÉ D'INVENTAIRE DES PIÈCES
F — FAST (rapide)
M — MEDIUM (moyen) S -SLOW (lent)
0 - Commande du client seulement
Page 19
NOTE: DÉCALQUES (voir p. 2 & 3)
NOTE: DECALS SEE PAGE 2 & 3.
