MODEL
207EDSS
1 2. Presser foot
13. Needle damp
14. Slide plate
15. Needle plate
16. Bed plate
17. Arm of machine
18. Stitch Regulator dial
(Reverse button)
19. Stop motion knob
20. Balance wheel
21. Bobbin winder
22. Spool pins
23. Zigzag dial (lever)
24. Presser bar lifter
25. Thread cutter
26. Sewing light switcli
27. Needle position lever
(Reset lever)
28. Pressure regulator
29. Drop feed
30. Stretch
stitch
selector lever
REPLACING THE NEEDLE
NEEDLE
CLAMP
Note; Use standard 15 X 1 needles,
ovoiloble at all sewing mochine stores. (For
correct size consult chort on page 4).
-FLAT
SIDE
To replace the needle, raise the needle (11)
to its highest point by turning the balance
wheel
(20)
TOWARD
YOU
by
hand.
Loosen the needle clamp screw (A)
F,9. 3
Remove the present needle ond slide the new needle
up
into the needle clomp
(13) I
flat
side
toward
the
balance
WHEEL '
i
as for as it will go.
When the needle hits the top it is m correct position, then fasten the needle
clomp securely. For best sewing results chonge needles frequently.
