dentification
chart
Lower looper thread____
tension dial
Upper looper thread
tension dial
Needle thread tension
dial
Thread guide
Cover plate
Release lever
Base
Protection cover
SPECIFICATION OF MACHINE
Thread guide
pole
Tension release
lever
Extension
plate
Spool pin
base
Hand wheel
Plug connector
socket
Light and power
switch
Front cover
ITEM
SPECIFICATION .............................................................. ^----------------
Number of Threads
2 or 3 Threads _________________________________________
Overedge Stitch Width
3 5 mm Narrow 12 mmi and Rolled Hems
Needle
HA
X
ISP, HA
x
1 (130/705 H)
Stitch Length
1 — 5 mm ____________________________ _________________—
Stitching Speed
U
d
to 1500 stitches per minute
Dimensions
325 mm(W) x260 mm(D) x275 mm(H)
Weight
9.2 Kg. ........................................................................... .........................
Presser foot lever
Presser foot
Needle plate
Stitch length
dial
Side cover
FRONT COVER OPENED
Threading char
Stitcfi selector knot
Moving cutter
Upper looper
Lower looper
Bolt for adjusting machine balance
