18. SNAP-ON TYPE PRESSER FOOT
• The following snap-on type presser foot
specially prepared for this machine are
available at extra-charge.
Note: Do not use presser foot made for other
machines. Use of such presser foot may
result In Interference with the needle and
can be hazardous.
• The snap-on type presser foot of this machine
permits easy removal and replacement.
A
Caution:
Be sure to disconnect the power line plug or
turn off the power switch when changing the
presser foot.
Removal
Raise presser foot and raise needle bar to its
highest position.
Press red colored lever (A) located on back
of clamp under the presser foot shank, raise
presser bar lifter to its High Lift position and
while holding the presser bar lifter in this
position, remove the presser foot plate.
Replacement
• Place presser foot plate on throat plate under
presser foot shank so that hinge pin (C) will fit
in slot (B) of the shank. Then lower presser bar
lifter.
• If presser foot plate can not be placed under
presser foot shank easily, raise presser bar lifter
to its High Lift position and while holding it in this
position, place presser foot plate under presser
foot shank. Then lower presser bar lifter. •
• Raise presser bar lifter and make sure the
presser foot plate Is properly attached to the
presser foot shank.
