While holding thread with fingers, pass it between the
tension discs and pull thread down to make certain It Is
properly located in between the tension discs 3.
Turn the hand wheel toward you until the chain stitch
looper extends out 10mm from the throat plate edge.
Thread the looper area of the machine following the
yellow color-coded thread guides 4~10.
Note: Use the tweezers provided in the accessory case
to aid In threading the looper.
Place the thread with the point of the tweezers through
threading guide 4.
Place the thread with the point of the tweezers through
the front slot of threading guide 5.
Place the thread with the point of the tweezers through
threading guide 6,7 and 8.
Thread the looper eye (A) from front to back.
Pull about 10cm (4 inches) of thread through the
looper. Position thread into V cutout (B) on threader.
Firmly hold thread tall with left hand and pull threader
lever (C) up into place (D).
