*7a
Wind tUe B
o
M
m
1. To wind the bobbin the balance wheel must be disconnected from the stitching mechanism. Hold the balance
wheel with your left hand and turn the clotch (Fig. 1 ( toward you with your right hand. This will permit
the hand wheel to turn freely while the needle bar remains motionless. The balance wheel is now
disconnected for the bobbin winding operation.
2. Place a spool of thread on the spool pin ».Fig. 1).
Draw thread from spool over guides, then down
ward across machine from left to right.
3.
Pass the thread through the tension discs at the
right corner of the base of the machine.
4.
Now wind the end of the thread around an empty
bobbin seven or eight times and place the threaded
bobbin on the spindle of the bobbin winder.
5.
By pressing on the bobbin winder lever, the small
rubber wheel is brought in contact with the balance
wheel. To lock into position, press bobbin winder
lever
until
a
click
is
heard.
The
bobbin
winder
release latch is now touching the shaft of the bobbin.
It holds the bobbin in place.
Pig. 1
