THREADING THE BOBBIN CASE
Pull thread at least 3 inches from bobbin.
Insert bobbin in bobbin case so that
thread will unravel clockwise.
Fig. 1
. Slot
• Thread
Pull thread into slot of bobbin case
as shown in Fig. 2.
Fig 2
Draw thread under the tension spring and
into the fork-shaped opening of the spring
as shown in Fig. 3.
Tension Spring
Fig. 3
Fig.
4
F.g. 5
Pull thread through hole in bobbin case
finger as shown in Fig. 4.
(Recommended for zigzag sewing only)
TO ADJUST BOBBIN TENSION
Turn screw on side of bobbin
case clockwise to increase
tension.
Turn screw on side of bobbin
case counterclockwise to
decrease tension.
CORRECT
INCORRECT
TOP TENSION TIGHT
BOTTOM TENSION LOOSE
INCORRECT
TOP TENSION LOOSE
BOTTOM TENSION TIGHT
