Corariectìng the Ice and Water Dlspeni
Connect the Ice end Water
System to Cold Water
Supply.
Refer to the instructions on the back of
the cabinet.
ACAUTION:
To avoid cross threading and
water ieaks, you must start all the
water tube fittings several turns by
hand before tightening with
wrenches. 00 NOT OVER­
TIGHTEN. Also be sure to double
check for water leaks after turning
on the water pressure to the
refrigerator.
Placement and Leveling
Placement
On some counter tops there is a 1”
overhang, if this is the case, the front
corners of the counter top must be
trimmed off at a 45° angie for the refrig­
erator and freezer door clearance |see
Rgure 15) To build in your refrigerator a
Perimeter Trim Kit is available at an
additional cost,
A recessed electrical outlet installed on
the back kitchen wall allows for a built-in
instaliation of your refrigerator.
To build In your refrigerator with other
options, such as wood or laminate con-
suit with a local kitchen designer.
FIGURE 15
Leveling
Instaii the unit on a solid floor that is
strong eriough to support the combined
weight of the unit, approximately 320
lbs.; and the food, maximum of 625 lbs
with an appraximate combined weight
of 945 lbs.
The unit must be level to insure com-
pteie door closings and proper ice mak­
ing. improper leveling will cause water
spills and uneven ice cube size.
Units have front wheels that can be
adjusted by turning a screw as shown in
Figure 16
/7yyVZ'7>
TO* a*
1 cauHim :
n
TQFVIEWQFXSNMQnE |
20 CU FT. flEFR K5 EilATOfl |
b , J
... (
i TO» 0» \
j iOlliiTtlt /
J_ _
1
__
)
.......... ^[^-(--=====4
FltFUtn BflOJ! [
M «iirXiBIRATQA OOOn
\j" 1
A CAUTION
To Avoid Property Damage to soft
vinyl flooring follow the floor prod­
uct manufacturer’s recommenda­
tions when installing or moving
the refrigerator.
If the floor is uneven from side to side,
place thin metal plates under one of the
rear wheels.
POWER SWITCH
Located behind the toe grille in the cen­
ter is a switch. This switch must be in
the on position before you proceed any
further.
SWITCH
