Door Assembly Removal
To Remove The Door
Assemblies (Do WOT remove
the door handies)
Tools Needed: Philips Screwdriver
and a
s
/
m
Nut Driver
S3) SCREWS
A
WARNING
TO AVOID THE RISK OF
DCDOr\KIAl IK1 II IDV AO nCTATI4
DISCONNECT TH£ POWER
DCrC’rf^QC DOAACTCPilKlA
DCeii VviiCL t AViiJi^I^Vi?:
1. Remove the toe grie.
2. Open refrigerator door to gain
access to door closure screw. See
Rgure 6A.
3 Unscrew bottom refrigerator door
closure screw with a Phillips
4. Disconnect wire harness at
connector. Push lock tab on
underside of connector up and then
pul! loose. See Rgure 7
FIGURE?
A
CAUTION
T
o
Avoid the Risk Of Personal
Injury Or Proper ty Damage
tape the top of the doors as
shown in Rgure 8,
FIGUR!
6. Remove the top hinge covers. See
Rgure 9.
wires. See Rgure 10.
DISCONNECT THE TOP HtNGE WIRES
A
WARNING THE
POWER CORD MUST &
DISCONNECTED.
^0
5
? PHliUPS
PHliUOS SCR£
SECURES THE
CSROUNO WIRE
PUU.THEELECTHÌCAL
CONNECTOR APART
FIGURE 10
FREEZER DOOR TOP HINGE SHOWN
(THE FRESH FOOD TOP DOOR
HiNGE HAS NO WIRES,!
