background image

Replacement Parts

- *8MPL

{Natural Gas)

Models - '8MPL050B12B1, ’8MPL075B12B1, *8MPL075F16B1, *8MPL100F20B1, '8MPL100J20B1, ’8MPL125J20B1

Replacement part supplied will be current active part. For parts not listed, consult place of purchase.

Key

No.

Description

Functional

Part

Number

050B

12B1

‘075B

12B1

•8W

075F

16B1

PL

100F

20B1

100J

20B1

125J

20B1

A

Panel, Top

1013982

1

1

-

-

-

-

1013983

-

-

1

1

-

-

1013984

-

-

-

-

1

1

B

Box, Junction

1172860

1

1

1

1

1

1

C

Cover, Junction box

1012350

1

1

1

1

1

1

D

Partition, Blower

1014009

1

1

-

-

-

-

1014010

-

-

1

1

-

-

1014011

-

-

-

-

1

1

E

Flousing, Blower

1172885

1

1

-

-

-

-

1172969

-

-

1

1

1

1

F

Hanger, Blower

1012328

2

2

2

2

2

2

G

Panel, Blower Cutoff

721020013

1

1

-

-

-

-

721020008

-

-

1

1

1

1

H

Clamp, Capacitor

1170643

1

1

1

1

1

1

J

Bracket, Control Mounting

1172845

1

1

1

1

1

1

L

Door, Blower (Heil/Arco)

1173011

1

1

-

-

-

-

(Heil/Arco)

1173012

-

-

1

1

-

-

(Heil/Arco)

1173013

-

-

-

-

1

1

(Comfortmaker Only)

1173008

1

1

-

-

-

-

(Comfortmaker Only)

1173009

-

-

1

1

-

-

(Comfortmaker Only)

1173010

-

-

-

-

1

1

(Tempstar Only)

1173014

1

1

-

-

-

-

(Tempstar Only)

1173015

-

-

1

1

-

-

(Tempstar Only)

1173016

-

-

-

-

1

1

M

Bracket, Door

1172231

1

1

-

-

-

-

1172232

-

-

1

1

-

-

1172233

-

-

-

-

1

1

N

Door, Louver (Heil/Arco)

1173005

1

1

-

-

-

-

(Heil/Arco)

1173006

-

-

1

1

-

-

(Heil/Arco)

1173007

-

-

-

-

1

1

(Comfortmaker Only)

1173002

1

1

-

-

-

-

(Comfortmaker Only)

1173003

-

-

1

1

-

-

(Comfortmaker Only)

1173004

-

-

-

-

1

1

(Tempstar Only)

1013609

1

1

-

-

-

-

(Tempstar Only)

1013610

-

-

1

1

-

-

(Tempstar Only)

1013611

-

-

-

-

1

1

P

Manifold, Gas

1013478

1

-

-

-

-

-

1013479

-

1

1

-

-

-

1013480

-

-

-

1

1

-

1013481

-

-

-

-

-

1

S

Bracket, Manifold Support

1012377

2

2

2

2

2

2

T

Top, Burner Box

1013705

1

1

1

-

-

-

1013015

-

-

-

1

1

-

1013016

-

-

-

-

-

1

u

Bracket, Burner Box Sides

1012532

2

2

2

2

2

2

V

Baffle, Burner Box

1012338

1

1

1

-

-

-

1012339

-

-

-

1

1

-

1012340

-

-

-

-

-

1

w

Bottom, Burner Box

1172847

1

_

_

_

_

_

1172848

-

1

1

-

-

-

1172849

-

-

-

1

1

-

1172850

-

-

-

-

-

1
