Circulation Air Blower Data Continued
N8MPN/L125J22 (2){6)
O im.
3
(A
^ .
£ o
O
o
w s
c3 "o
c _c
0)
w
X
LU
8MPN150J20 (2){7) * Denotes Brand
Air Delivery In Cubic Feet per Minute (C.F.M.)
{Furnace Rated @0.5" WC ESP)
TAP LOW MED L MED H HIGH
.10 1901 2121 2362 2463
.30 1833 2033 2244 2385
.50 1745 1936 2100 2217
.70 1624 1773 1894 2033
.90 1442 1569 1714 1821
1.00 1329 1455 1583 1685
*
3
(/)
£ o
w ®
ui «
_ £
ni y
c c
X
LU
Air Delivery in Cubic Feet per Minute (C.F.M.)
(Furnace Rated @0.5" WC ESP)
TAP LOW MED L MEDH HIGH
.10 1656 1915 2168 2385
.30 1583 1787 2090 2335
.50 1507 1697 1997 2212
.70 1390 1595 1856 2085
.90 1212 1445 1654 1898
1.00 1125 1337 1561 1777
NOTE: (1) Data based on Bottom Only or One Side return.
(2) Data based on Both Sides or Bottom plus One Side
(3) 075F16 Reduce airflow by 5% if Bottom Only return.
(4) 100F20 Reduce airflow by 10% if Bottom Only return.
(5) 125J20 Reduce airflow by 5% if Bottom Only return.
(6) 125J22 Reduce airflow by 10% if Bottom Only return.
(7) 150J20 Reduce airflow by 10% if Bottom Only return.
MAX CFM's
Filter Size CFM
14" X 25" 1400
16" X 25" 1600
20" X 25" 2000
24" X 25" 2500
Max CFM based on 600 FPM
Filter required for each return-air inlet. Airflow performance includes 1" washable (600 FPM max) filter media.
441 01 2613 02
THIS DATA IS SUBJECT TO CHANGE WITHOUT NOTICE
