Replacement Parts - N8MPL
(Natural Gas)
Models - N8MPL050B12B1, N8MPL075B12B1, N8MPL075F16B1, NSMPL100F20B1, N8MPL100J22B1, N8MPL125J20B1,
N8MPL125J22B1
Replacement part supplied will be current active part. For parts not listed, consult place of purchase.
Key
No.
Description
Functional
Part
Number
N8MPL
050B12B1 075B12B1 075F16B1 100F20B1 100J22B1 125J20B1 125J22B1
1 Heat Exchanger 1014322 1 - - - - - -
1014323 - 1 - - - - -
1014324 - - 1 -
- - -
1014325
- -
- 1 -
-
-
1014326 - - - - 1 - -
1014327
- - - - -
1 1
2 Switch, Pressure 1013529 1 1 1 1 1 1 1
3 Wheel, Blower 1013011 1 1
- - - - -
1011420
- -
1 1 1 1 1
4 Mount, Motor kit* 1014824 1 1
- - - - -
1014823 - - - 1 1 1 1
1014822
- -
1
- - - -
5 Mtr, Blower 1/115 V 2 CCW 1172490 1
_
1
_ _ _ _
1/115 V 2 CCW 1172487
-
1
- - - - -
1/115 V 2 CCW 1172488
- - -
1
-
1
-
1/115 3 / 4 CCW 1172489
- - - -
1
-
1
6 Capacitor, 7.5 Mfd/370V 1171728
_
1
_ _ _ _ _
10Mfd/370V 1171729 1
-
1 1
-
1
-
40 MFD/370V 1171982 - - - - 1 -
1
7 Transformer 1172810 1 1 1 1 1 1 1
8 Control 1172550 1 1 1 1 1 1 1
9 Switch, Interlock 1171981 1 1 1 1 1 1 1
10 Burner Assembly 1172884 1
_ _ _ _ _ _
1172965 - 1 1 - - - -
1172966 -
- -
1 1
- -
1172967
- - - - -
1 1
11 Flame Sensor 1172827 1 1 1 1 1 1 1
12 Ignitor 1172533 1 1 1 1 1 1 1
14 Orifice, Burner # 42 1011351 2 3 3 4 4 5 5
15 Valve, Gas 1172821 1 1 1 1 1 1 1
16 Switch, Limit (Rollout) 1013102 2 2 2 2 2 2 2
17 Switch, Limit (Main) 1008417
_ _ _
1
_ _ _
1320362 1 1 - - 1 - 1
34335000
- -
1
- -
1
-
18 Blower, Combustion 1013517
_ _ _
1 1 1 1
(Inducer) 1014433 1 1 1
- - - -
*See Table below for beliyband location on motor
Beliyband Location
on Motor
Model N8MPL A(in.)
050B12B1 1.38”
075B12B1 1.38"
075F16B1 1.38”
100F20B1 1.81”
100J22B1 1.65”
125J20B1 181"
125J22B1 1.65”
