CONTENTS OF HARDWARE PACK

Parts Bag contents shown full size

(2) Screws #10

X

5/8

(2) Lock Washers #10

f\

Z

'

~

(2) Washers 3/16 x 3/4 x 16 Gauge

e

■II

(2) Hex Bolts 1/4-20x3/4

{2) Hex Nuts 1/4-20

o

(2) Washers

9/32 x5/8x16Ga.

(2) Lock Washers 1/4

Parts packed separately In carton

Manual

Parts Bag

Parts bag contents not shown full size

(2) Shoulder

Bolts

(2) Center­

lock Nuts

(2) Washers 3/8
x 7/8 X 14 Gauge

0^

11- T 1

(2) Latch Hook

Assemblies

Steering

Sleeve

(2) Gauge

Wheels

”D----D'

Steering

Wheel

Insert

-m (2) Keys

Slope Sheet
