DRIVE
REPAIR PARTS
TRACTOR - - MODEL NUMBER 917.256600
KEY PART KEY PART
NO. NO. DESCRIPTION NO. NO, DESCRIPTION
1 145607 Transaxle, Dana, Model Number 44 105706X Bearing
4360-97 45 110812X Washer, Hardened
2 146682 Spring, Brake Return 46 12000039 Ring, Clip
3 123666X Pulley, Transaxle 47 127783 Pulley, Idler
4 STD582075 Ring, Retainer 48 123789X Arm, Idler
5 121520X Strap, Torque 49 123205X Retainer, Belt
6 17490512 Screw, Hex, Washer, Thread 50 STD523715 Bolt, Hex 3/8-16 x 1-1/2
Rolling 5/16-18x3/4 51 STD541437 Nut, Crowniock 3/8-16
1:A5fi2ar Rod, Shifter 52 STD541431 Nut, Lock Hex w/lns 5/15-18
9 Í37MQ- Clutch, Electric 53 10571OX Link, Clutch
10 5TD56T210 Pin, Cotter 1/8x1 54 2751R Clip Line Fuel 13/32 Mtg Hole
11 105701X Washer, Shift Plate 55 105709X Spring, Return, Clutch
12 19151216 Washer 15/32 x 3/4 x 16 Ga. 56 STD523712 Bolt, Hex 3/8-16 X 1-1/4
13 74550412 Bolt 1/4-28 UNF Gr. 8 w/Patch 57 130801 V-Belt, Drive
14 STD551125 Washer Lock 58 127274X Keeper, Belt, Transaxle, R.H.
15 74490544 Bolt Hex FIghd 5/16-18 Gr. 5 59 140312 Retainer, Belt
16 STD541431 Nut Lock Hx W/lns 5/16-18 UNC 60 121218X Keeper, Belt, Engine, LH
18 STD523710 Bolt 61 17490612 Screw, Hex Washer Head, Thd.,
19 STD541437 Locknut 3/8-16 Roll. 3/8-16x3/4
20 71170768 Bolt, Hex 7/16-20x4-1/4 62 8883R Cover, Foot Pedal
21 106933X Knob 63 145868 Pulley, Clutch Electric Evx
22 130804 Rod, Brake 65 STD551143 Washer, Lock Hvy Hid Spr 7/16
23 140275 Bracket Assembly, Clutch 68 105730X Belt Keeper, Engine
24 STD541237 Nut, Hex Jam 3/8-16 74 109502X Spacer, Split
25 106888X Spring, Rod, Brake 75 121749X Washer 25/32 x 1-1/4 x 16 Ga.
26 STD551037 Washer 13/32 x 13/16 x 16 Gauge 76 STD581075 E-Ring
27 STD561210 Pin, Cotter 1/8 X 3/4 77 123583X Key Square
28 145204 Rod, Brake, Park 78 121748X Washer 25/32 x 1-5/8 x 16 Ga.
29 124236X Cap, Plunger 80 131487 Shift Arm
30 130807 Bracket, Transaxle, L.H. 81 136933 Shaft, Assembly, Shifter
31 127275X Keeper, Belt, Transaxle, LH. 82 123782X Spring, Torsion
32 STD523107 Bolt Hex Hd 5/16-18 UNC x 3/4 83 19171216 Washer 17/32 x 3/4 x 16 Gauge
33 STD533107 Bolt,Carriage 5/16-18x3/4 84 132183 Rod, Tie
34 149001 Shaft, Foot Pedal 85 150360 Nut Lock Center 1/4-28
35 120183X Bearing Nylon 86 71208 Bushing, Rod, Steering
36 STD551062 Washer 21/32 x 1 x 16 Gauge 87 19212016 Washer 21/32 x 1-1/4 x 16 Gauge
37 STD571810 Pin,Roll 3/16 X 1 88 12000008 Ring, Klip
38 123674X Idler, Flat 89 139991 Console, 6 Speed
39 STD523727 Bolt, Hex 3/8-1 6 X 2-3/4 90 124346X Nut, Washer Head, Self-Thread 1/4
40 4470J Spacer 114 19111214 Washer 11/32 x 3/4 x 14 Ga.
41 109070X Keeper, Belt
NOTE: All comoonent dimensions aiven in U.S. inches
42 19131312 Washer 13/32 x 13/16 x 12 Gauge
1 inch = 25.4 mm
