FEATURES
PRODUCT SPECIFICATIONS
Chuck........................................3/8 in. (10 mm) Keyless
Motor........................................................ 14.4 Volt DC
Switch................................................... Variable Speed
Gear Train.........................................................1 Speed
No Load Speed............................................... 0-650/min.
KNOW YOUR DRILL-DRIVER
See Rgure 1,
Before attempting to use your drill-driver, familiarize
yourself with all operating features and safety
requirements.
WARNING:
Carefully read through this entire
operator’s manual before using your new drill-driver.
Pay close attention to all Safety Rules, Warnings and
Cautions. If you use your drill-driver property and
only for what it Is Irrtended, you wHI enjoy years of
safe, reliable service.
WARNING:
Do not allow familiarity with your drill
driver to make you careless. Remember that a
careless fraction of a second Is sufficient to inflict
severe injury.
KEYLESS CHUCK
Your drill-driver has a keyless chuck that allows you to hand
tights or release drill bit in the chuck jaws.
DIRECTION OF ROTATION SELECTOR
FORWARD/REVERSE
Your drill-driver has a forward/reverse selector located
above the switch trigger. The switch trigger can be locked
in the
OFF
position.
Clutch......................................................... 4 Positions
Charger input........................ ........120 V. 60 Hz, AC only
Charge Rate................................................... 3-6 Hours
Torque..............................................................OOtn.lb.
SWITCH TRIGGER
To turn your drill-driver
ON,
depress the switch trigger.
Release switch trigger to turn your driJJ-driver
OFF,
VARIABLE SPEED
This tool has a variable speed switch that delivers higher
speed with increased trigger pressure. Speed is controlled
by the amount of switch trigger depression.
BIT STORAGE
When not In use, bits provided with your drill-driver can be
placed in the storage area located on the top of the motor
housing.
TORQUE ADJUSTMENT RING
Your drill Is equipped with an adjustable torque ring for
driving different types of screws into different materiais.
The proper setting depends on the type of material and
the size of the screw you are using.
