OPERATION

SCREWDRIVING
TORQUE ADJUSTMENT

(Driving power of your drill-driver)

When using your drill-dilver for various driving applica
tions, It becomes necessary to increase or decrease the
torque in order to help prevent the possibility of damaging
screw heads, threads, workpiece, etc. in genera/, torque

should correspond to the intensity of the screw diameter.

If the torque is too high or the screws too small, the

screws may be damaged or broken.

The torque is adjusted by rotating the torque adjustment

ring. See Figure 7. The torque is greater when Che torque
adjustment ring is set on a higher setting. The torque is
less when the torque adjustment ring Is set on a lower
setting.

The proper setting depends on the type of material and the

size of screw you are using.

TO ADJUST TORQUE

■ identify the four torque indicator settings located on

the front of your drill. See Figure 7.

■ Rotate adjustment ring to the desired setting.

• Position t:

For driving small screws.

• Position 2:

For driving screws Into soft material.

■ Positron 3:

For driving screws into hard wood.

•

For heavy drilling.

BIT STORAGE

See Rgure 8.

When not in use, bits provided with your drill can be
placed In the storage area located on the top of your drill
as shown in figure 8.

TO DECREASE

TORQUE

ADJUSIMEKTRING

Fig. 7
