OPERATION
LATCHES
DEPRESS UTCHES TO ^
RaEASE BATTERY PACK
Fig. 4
SWITCH
See Rgure 5.
Your drill starts and stops by depressing and releasing the
switch trigger. Release the switch trigger to turn drill
OFF.
VARIABLE SPEED
See Figure 5.
Your drill has a variable speed feature in the swltr^. The
switch delivers higher speed and torque with increased
trigger pressure. Speed is controlled by the amount of
switch trigger depression.
SWITCH LOCK
See Figure 5.
The switch trigger can be locked in the
OFF
position. This
feature helps reduce the possibility of accidental starting
when not in use. To lock the switch trigger, place the direction
of rotation selector In the center position.
REVERSIBLE
See Rgure 5,
This tool is reversible. The direction of rotation is controlled
by a selector located above the switch trigger. With the drill
held in normal operating position, the direction of rotation
selector should be positioned to the left of the switch for
drilling. The drilling direction is reversed when the selector is
to the right of the switch. When the selector is In center
position, the switch bigger is locked.
CAUTION:
To prevent gear damage, always allow chuck
to come to a complete stop before changing the direction of
rotation.
To stop, release switch trigger and allow the chuck to come
to a complete stop.
WAITING:
Battery
tools
are
always
in
operating
corKfltion. Therefore, switch should alwa^ be locked
when not In use or when carrying at your side.
DIRECTION OF
ROTATION SELECTOR
(FORWARD/REVERSE)
REVERSE I
CENTER POSITION
(LOCK)
FOFWARD
SWITCH TRIGGER
Fig. 5
KEYLESS CHUCK
See Figure 6.
A keyless chuck has been provided with your drifi to allow for
easy instaUatlon and removal of bits. As the name Implies,
you can hand tighten or release drill bits in the chuck ¡aws.
Grasp and hold the collar of the chuck with one hand. Rotate
the chuck body with your other hand. The arrows on the
chuck indicate which direction to rotate the chuck body in
order to GRIP (tighten) or RELEASE (urtiodc) the drill bit.
WARNING:
Do not hold the chuck body with one
hand and use the power of the drill to tighten chuck
jews on driR bits. Chuck body could slip in your hand
or your hand could slip and come In contact with
rotating drill bit. This could cause an accklant resulting
in serious personal injury.
RELEASE
(UNLOCK)
KEYLESS
