Guide specifications
Furnish and install a 2-compressor air-to-air electric
heat pump that includes outdoor coil section and indoor
compressor section. The combined heat pump sections
shall be used in systems with matching indoor fan/coil/
electric heater (40FS/28HQ,VQ/40FQ) assembly.
Compressor shall operate with one or both compressors
in response to indoor heating requirements or with one
compressor for indoor cooling requirements
Sound Rating Number (SRN) of outdoor coil section
shall be______ or less at full capacity Indoor compressor
section shall be acoustically treated to muffle operating
sound. Brass service valves with refrigerant line fittings and
service ports shall be located on exterior of outdoor section
Indoor section shall be equipped with refrigerant line
fittings and service ports
Normal electrical characteristics of combined heat pump
unit shall be_____ v, _____ ph, ______ Hertz. Units shall
be capable of satisfactory operation within voltage range
of_____ V to ____ volts.
Total cooling capacity shall be not less than_______ Btuh
with indoor air quantity of______ cfm at_____ F wet-bulb
temperature coincident with.
_F dry-bulb temperature
of air entering outdoor unit. Sensible heat capacity shall
be not less than_______Btuh with______F room dry-bulb
temperature. Unit cooling per watt of electric power shall
be_____ Btuh or more.
Heating capacity at (one compressor) (two compressor)
operation shall be not less than_____ Btuh with air entering
outdoor unit at_______ F dry-bulb temperature at 85%
relative humidity, and_____ F dry-bulb temperature of air
entering indoor unit. Compressor motor power input shall
be_____ kw or less at these conditions. One_________ kw
electric heater shall be provided for indoor fan-coil unit.
Outdoor coil section shall be of circular construction.
Coil shall be____ rows deep with a nominal fin spacing of
_____fins per in. and have a total face area of_____square
feet. Aluminum plate fins shall be mechanically bonded to
aluminum tubing with all joints brazed. Coil shall be
protected by vinyl coated grille. Factory-installed coil
refrigerant metering device shall be mounted on unit liquid
service valve. Metering device internal components shall
be removable for cleaning or replacement.
Outdoor section fan shall be propeller-type, direct-driven,
and arranged for vertical air discharge. Fan motor shall
be factory lubricated, inherently protected and resiliently
mounted.
Indoor compressor section shall include two com­
pressors, top-mounted control box, reversing valve and
suction line accumulator. Electrical and refrigerant connec­
tions shall be on top of unit. Top service panel and side
service wrapper shall provide access to all piping and
components
Compressors shall be of the welded-hermetic type with
internal vibration isolation. Compressor motors shall have a
thermal/current-sensitive overload device and start
capacitor and relay shall be standard Compressors shall
be equipped with crankcase heaters and relay and have
internal high-pressure relief. Total unit power input shall
not exceed_____ kw at specified conditions.
Controls — Factory-wired controls shall be located in the
indoor compressor section control box (defrost thermostat
located in outdoor coil section). Factory-supplied, field-
wired
controls shall include compressor outdoor
thermostat.
Controls and protective devices that units come
equipped with are low-pressure switch, and compressor
malfunction warning device. This device energizes light
on indoor thermostat if safety control shuts compressor(s)
off or if compressor(s) does not operate when required.
An automatic defrost control shall be included to accom­
plish defrosting (only if coil saturated suction temperature
indicates freezing temperatures) every 90 minutes for a
period of not more than 10 minutes. Control wiring terminal
board shall be designed to match indoor unit terminal
board and compression unit terminal board and accessory
thermostat terminals for standardized point-to-point
connection. Indoor fan speed controller shall be included to
increase indoor fan speed during periods in which both
compressors are running.
Maximum dimensions of indoor compressor section are:
width_____in., depth______in., height_____ inches.
Maximim dimensions of outdoor coil section are:
diameter_____ in., height_____ inches.
Accessories shall include (Indoor Thermostat), (Outdoor
Thermostats), (Liquid Line Filter-Drier), (Emergency Heat
Relay), (Heat Pump Stand), (Flare-to-Compatible Coupler),
(Tubing Packages), (Optimizer Control), (Hot Shot heat
reclaim device), (Solid State Time Guard II® device).
Number One
Air Ctonditbning
I\Mer
e
Division of
Cairici CorpoiiK
Cürriur Piiikw.iy • Syracuse N Y 13221
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
