User Manual
- ONLINE 6K/10K RACK-TOWER ISOTX UPS
ENGLISH
__________________________________________________________________________________________________________________________
www.xmart-ups.com 130717 RT9- 6K-10K (ENG) - 35
F4. SETTING FUNCTIONS
This menu is used to adjust most important parameters of the UPS as described in below screen. Some of below settings cannot be
changed in all operation modes. Please check functions availability according to UPS mode in first page of this section.
Setting:
--> Bypass
ECO
Output
Battery
Calibration
Others
SETTING / BYPASS
Bypass:
--> Status: Open
Enable
High Loss V: 264V
Low Loss: V: 110V
High Loss: F: 54Hz
Low Loss: F: 46Hz
Bypass:
--> Status: Forbid
High Loss V: 264V
Low Loss: V: 110V
High Loss: F: 54Hz
Low Loss: F: 46Hz
.
STATUS OPEN: Bypass allowed: UPS will run at bypass depending on
ENABLE/DISABLE parameter setting.
STATUS FORBID: Bypass NOT allowed under any situation.
ENABLE: This option is available when previously has been selected
OPEN option. ENABLE allows bypass mode.
DISABLE: Manual bypass NOT allowed so when UPS is turned off it
will not go to bypass mode. Instead of that UPS will go to output
power off condition.
HIGH LOSS V: Acceptable high limit for input voltage for UPS in
bypass mode.
LOWLOSS V: Acceptable min. limit for input voltage for UPS in bypass
mode.
HIGH LOSS F: Acceptable high limit for input frequency for UPS in
bypass mode.
LOWLOSS F: Acceptable min. limit for input frequency for UPS in
bypass mode.
