Page 12 3025-00 60706-240
TROUBLESHOOTING TABLES
UNIT WILL NOT CRANK WHEN THE POWER FAILS
1. DSE Controller not in "AUTO".
2. Transfer control switch not in "AUTOMATIC"
position.
3. Incorrect wiring between transfer switch and
generator.
4. Blown fuses on engine control box.
5. Defective DSE Control.
6. Loose or dirty battery terminals.
7. Defective auto start controller in the
transfer switch.
8. Defective starter.
9. Defective start solenoid.
10. Defective ECU on engine.
ENGINE WILL NOT CRANK WITH GENERATOR
RUN PUSH-BUTTON DEPRESSED
1. Battery dead.
2. Blown fuses on engine control box.
3. Defective DSE Control.
4. Loose or dirty battery terminals.
5. Defective starter.
6. Defective start solenoid.
7. Locked up engine genset.
8. Defective ECU on the engine.
ENGINE CRANKS BUT WILL NOT START
1. Improper fuel pressure being delivered to
unit.
2. Fuel supply shut off.
3. Fuel tank empty.
4. Defective spark plug.
5. Defective engine ignition module.
6. Dirty air cleaner filter.
7. Defective fuel solenoid valve.
8. Low battery.
9. Defective fuel regulator.
10. Defective ECU on the engine.
ENGINE STARTS AND THEN STOPS AND ALARM
LIGHT COMES ON
1. Engine is low on oil.
2. Engine has high water temperature.
3. Engine has overspeed.
4. Engine has gone into overcrank.
5. No output from engine alternator to engage
stop crank circuit.
6. Generator is not operating at the correct speed.
7. Defective ECU on the engine.
ENGINE WILL NOT COME UP TO SPEED AFTER IT
STARTS
1. Insufficient fuel volume getting to the unit.
a. Too small of fuel line.
b. Fuel pressure too low/high.
2. Defective ECU on the engine.
3. Governor is defective.
4. AC short in generator components.
ATS PANEL WILL NOT TRANSFER TO EMERGENCY
SUPPLY (GENERATOR)
1. No AC generator output from generator.
2. Defective transfer switch controller.
3. Incorrect voltage or frequency from the generator.
4. Wiring error between generator and transfer
switch.
5. Defective mechanically switching solenoid in
Automatic Transfer Switch.
6. Improper phase rotating.
7. Main line breaker on generator open/defective.
ATS PANEL WILL NOT RETRANSFER TO NORMAL
POWER
1. Proper normal line power not available at line
terminals in ATS panel.
2. Defective transfer switch controller.
3. Defective mechanically switching solenoid in
Automatic Transfer Switch.
4. Retransfer delay still timing out.
NO AC OUTPUT FROM GENERATOR
1. Defective diode.
2. Defective voltage regulator.
3. Defective rotor.
4. Defective stator.
5. Defective exciter rotor.
6. Defective exciter stator.
7. AC short in the output leads.
8. Defective field circuit breaker.
CHANGING THE FUEL TYPE
**** CAUTION ****
EQUIPMENT DAMAGE - Do not make any fuel adjustments or
governor adjustments until all pressure readings are in compli-
ance with specification. See fuel pressure charts (tables 1, 2, and
3).
These engine/generator sets are very easy to convert between
LP or NG. As the engine timing is controlled by the ECU on the
engine you only need to tell the ECU what fuel you are operating
on. A small rocker switch has been provide on the underside of
the engine control cabinet (see ref G on Page 9) for this purpose.
Opening the rocker switch will tell the ECU mounted on the engine
that you are operating on NG Fuel. Closing the rocker switch will
tell the ECU that the fuel being supplied is LP. The ECU will then
reprogram the engine to operate on the proper fuel.
