1 | VZ7260W Series- Installation Guide
C
ONTENTS
Installation 2
Location 2
Installation 2
Theory of Operation 3
Features and benefits overview 3
Wireless System Overview 5
Terminal, Identification and Function 6
Wiring 6
Typical Applications 7
Main outputs wiring 7
Remote sensor accessories 11
CO2 sensor wiring 12
Configuring and Status Display Instructions 13
Status display 13
User interface 14
User configuration menu 14
Local keypad interface 15
Installer Configuration Parameter Menu 15
AI4 Input for CO2 Sensor 29
Referenced Operational Control Curves 30
Specifications Error! Bookmark not defined.
Drawing & Dimensions 38
VZ7260X5X00W
Zigbee™ Wireless Zone Terminal Equipment
Controller
Installa tion Guide
F o r C o m m e r c i a l Z o n i n g S ys t e m s
J u l y 2 7
t h
, 2 0 1 2 / 0 2 8 - 0 3 2 9 - R 3
