6 | PIR Ready VT7600 Series-Installation Guide
Network ready
ƒ All Viconics VT7600 series Terminal Equipment Controllers are designed for
stand-alone
(Network Ready) operation.
ƒ They can be fully integrated into your choice of automation systems using the
available communication adapter options.
ƒ If required, stand-alone (Network Ready) Terminal Equipment Controllers can be
field retrofitted with the following communication adapters:
o
VCM7600V5000B, Terminal Equipment Controller BACnet™ MS-TP®
communication adapter
o
VCM7600V5000E, Terminal Equipment Controller Echelon™
Lontalk™® communication adapter
o
VCM7000V5000W Terminal Equipment Controller wireless Zigbee™
communication adapter
T
ERMINAL
, I
DENTIFICATION AND
F
UNCTION
Wiring
Multistage 1H / 1C Heat Pump
Part Number
VT7656B VT7605B VT7652B VT7600B VT7652A VT7600A
Part
Number
VT7652H VT7600H
Schedule Yes No Yes No Yes No Schedule Yes No
Top left terminal block Top left terminal block
Y2 X X X X Y2 X X
Y1 X X X X X X Y1 X X
G X X X X X X G X X
RC X X X X X X RC X X
C X X X X X X C X X
Top right terminal Top right terminal block
RH X X X X X X RH X X
W1 X X X X X X W1 X X
W2 X X X X O/B X X
Bottom terminal block Bottom terminal block
Econo X X
Aux X X X X X X Aux X X
DI1 X X X X X X DI1 X X
DI2 X X X X X X DI2 X X
RS X X X X X X RS X X
Scom X X X X X X Scom X X
OS X X X X X X OS X X
MS X X X X X X MS X X
