Technical data
General technical data valid for all pumps
Maximum permissible inlet pressure
(absolute)
psi
(bar)
16
(1.1)
Maximum permissible outlet pressure
(absolute)
psi
(bar)
16
(1.1)
Maximum pressure difference between
inlet and outlet
psi
(bar)
16
(1.1)
Permissible ambient temperature
storage / operation
°F
(°C)
14 to 140 / 50 to 104
(-10 to +60 / +10 to +40)
Permissible relative atmospheric mois-
ture during operation (no condensation)
% 30 to 85
Maximum permissible installation alti-
tude above mean sea level
ft
(m)
6500
(2000)
Rated motor power hp (kW) 0.71 (0.530)
No-load speed rpm 30 - 2400
Maximum permissible range
of supply voltage (±10%)
Attention: Observe specifications of rating plate!
100-120 V~ 50/60 Hz,
200-230 V~ 50/60 Hz
Maximum rated current at:
100-120 V~ 50/60 Hz
200-230 V~ 50/60 Hz
A
A
8.0
3.5
Device fuse 2 slow blow fuses 8A
Motor protection thermal cutout, manual reset
Degree of protection IEC 529 IP 40
A-weighted emission sound pressure
level* (uncertainty K
pA
: 3 dB(A))
dB(A) 50
Inlet small flange KF DN 25
Outlet silencer / thread G 1/2”
Dimensions L x W x H
approx.
in
(mm)
21.8 x 10.2 x 16.5
(554 x 260 x 420)
Weight approx. lbs. (kg) 68.8 (31.2)
* Measurement according to EN ISO 2151:2004 and EN ISO 3744:1995 at 1500rpm and ulti-
mate vacuum with standard silencer at outlet.
