CVC 2 II
setting pressure unit (mbar / Torr / hPa)
configuration of the coolant valve if applicable
automatic identification of the solenoid operated in-line valve
setting basic setup
ready to
start
basic setup ”Standard” (factory-set)
controller switches
-
solenoid operated in-line valve (indispensable)
- coolant valve (optional)
basic setup ”Management”*
controller switches
-
pump
- solenoid operated in-line valve if connected
- coolant valve (optional)
basic setup ”VACUU•LAN”*
controller switches
-
pump according to preset pressure and time values
- solenoid operated in-line valve if connected
- coolant valve (optional)
* only in combination with Vacuum-Management-System VMS Module A
basic setup ”Management Plus”*
controller switches
-
pump, but with after-running to pump out condensate
- solenoid operated in-line valve (indispensable)
- coolant valve (optional)
General view basic setups
