exhaust waste vapour
condenser with cover
overpressure safety
relief device at the
exhaust waste
vapour condenser
round bottom flask to
collect condensate
PC 620
controller CVC 2
II
pump MD 4C
inlet with solenoid
operated in-line valve
(vacuum connection)
connection mains cable
mains switch
