page 10 of 48
exhaust waste
vapour condenser
with cover
overpressure safety
relief device at the
exhaust waste
vapour condenser
inlet (vacuum connection)
round bottom flask to
collect condensate
PC 510
controller CVC 2 II
pump MZ 2C
gas ballast valve
exhaust waste
vapour condenser
with cover
overpressure safety
relief device at the
exhaust waste
vapour condenser
inlet with solenoid
operated in-line valve
(vacuum connection)
round bottom flask to
collect condensate
PC 511
controller CVC 2 II
pump MZ 2C
gas ballast valve
inlet with manual flow
control diaphragm
(vacuum connection)
mains switch
connection mains cable
mains switch
connection mains cable
