Appendix A – Automation Commands
The
following
commands
can
be
sent
to
the
device
by
TCP/IP
ASCII
strings
on
port
10001
or
through
a
telnet
session
to
the
same
port.
Individual
commands
should
be
terminated
with
a
carriage
return
line
character,
often
shown
as
“\r\n”
or
“\x0A\x0D”.
The
terminal
will
accept
commands
in
the
communication
format:
hsw.sys.subsystem.command=value
System
Commands
Command
Assign/Query
Value
Description
hsw.sys.store
Yes
1
Saves
current
configuration
to
flash
storage
on
the
HSW.
Both
hsw.sys.store
and
hsw.sys.store=1
will
execute
the
save.
hsw.sys.source0.name
hsw.sys.source1.name
hsw.sys.source2.name
hsw.sys.source3.name
hsw.sys.source4.name
hsw.sys.source5.name
Yes
String
Query
or
assign
the
channel
name
for
HDMI
inputs
0-­‐5.
Inputs
are
0
referenced.
The
names
will
be
shown
in
the
Web
Interface.
Switching
Commands
hsw.live.source
Yes
0-­‐5
Assign
the
Live
output
to
the
specified
input
channel.
Inputs
are
0
referenced
(assigning
0
will
activate
input
1).
hsw.preview.source
Yes
0-­‐5
Assign
the
Preview
output
to
the
specified
input
channel.
Inputs
are
0
referenced
(assigning
0
will
activate
input
1).
Audio
Commands
hsw.audio.source
Yes
0-­‐2
Select
the
source
to
mix
to
the
AES
audio
output.
Assign
or
query
values:
0
–
None
1
–
Microphone
2
–
Line
In
hsw.audio.outputen
Yes
0
or
1
Enable
the
AES
audio
output.
Assign
to
1
to
set
HDMI
audio
to
play
on
AES
Out
and
mix
the
assigned
audio
source.
Set
to
0
to
have
the
AES
audio
pass
through
the
AES
In
audio.
